Professional manufacturer supply epdm and silicone rubber extrusion vulcnaizing line extrude machine

Supplier: Tianjin Hui Tian Electrical Technology Co., Ltd
Region: Tianjin, China
Price: $10500.00 /set
Min. Order: 1 set

Click here to contact

Product details

Screw rod type:	single thread, different distance and depth;	Motor type:	Inverter motor;
Place of Origin:	China;	Self life:	15 years;
After-sales Service Provided:	Field installation, commissioning and training;	Warranty:	1 Year;
Maximum extruding OD:	<200mm;	Port:	Tianjin;
Supply Ability:	100 Set/Sets per Month horizontal extruder;	Packaging Detail:	Wooden case;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,paypal;	Certification:	Patent ZL01224092.3;
Function:	Double-color tube, pipe extruding;	Voltage:	380V;
Weight:	900kg;	Silicone Extruder:	SiliconeTubeAndSiliconeStripMaking MachineHorzontalSiliconeExtruder;
Screw compression ratio:	2.5:1;	Material:	38CrMoAlA;
Brand Name:	Huitian;	Applicable Industries:	Manufacturing Plant;
Key Selling Points:	SiliconeTubeAndSiliconeStripMaking MachineHorzontalSiliconeExtruder;	Condition:	New;
Minimum extruding OD:	<0.5mm;	L/D Ratio:	12:1;
Power(W):	1.5-22;	Dimension(LWH):	16006451250;

Product Description

Product Application of Silicone Extruder

Silicon Rubber Extruder
(National patent: ZL01224092.3)
The silicone extruder can also extrude and produce hatching line, multi-cavity and multi-colored tubes and strips and pipes.

Unique Design of Silicone Extruder

1. The silicon rubber extruder has many special designs, such as the easy and convenient feeding, good plasticizing and self-cleaning ability of screw

2. The silicone rubber extruder extruded products with high density and stable and identical dimension, the screw and extrusion head can be dismantled and cleaned conveniently

3. When extruding the abnormal rubber strips with all kinds of complex section forms, it can guarantee the accurate dimension and form.

4. To all kinds of soft and hard silicon rubber with the hardness from 30 to 80 degrees, it can guarantee the excellent extrusion and cure effect with high production efficiency and easy operation.

5. The screw L/D ratio is 12: 1, the extruded products have good density.
6. The type of screw is unequally spaced and unequally deep, single screw thread. When the compression ratio is 2.5:1, it can extrude all kinds of soft and hard silicon rubber with the degree of 30 to 80 (Shore A hardness)well.
7. The filter plate which is in the front of screw can be installed with filter screen to reduce impurities of silicone.
8. By adopting the converter moter and FUJI frequency converter, the low speed and high speed of machine and the control ability of machine is very stable and excellent.
9. By adopting the floating type design, the screw can be easy to demount and clean. It is especially applicable to the production which needs to often change the color or Platinum silicone. The screw has excellent self-cleaning ability, and can completely empty silicone in the barrel .
10. The barrel and the cooling trough are in the same body. By using external spiral passage cooling method, the cooling effect is very good and the working temperature is below 40 degree Celsius.
11. It has the function of extruding the hatching line, it can extrude with two colors (three color) and extrude with different silicone such as conduction silicone etc. It is also applicable to the production of extruded products such as silic

Specification

	Ф16	Ф30	Ф50	Ф65	Ф75	Ф90
Screw OD	Ф16	Ф30	Ф50	Ф65	Ф75	Ф90
Screw Length-dia Ratio	12:1
Screw Compression ratio	2.5:1
Screw Type	Single Screw Thread, Unequally Spaced, Unequally Deep
Rotating of Screw(RPM)	0-60/MIN
Motor Power (kw)	1.5	3	7.5	11	15	22
Center Height(mm)	1000
Capacity of the extruder(KG/H)	10	20	50	100	150	200
Size(mm)
Length	650	975	1500	1600	1700	1900
Width	480	620	700	700	700	700
Height	1140	1140	1160	1250	1250	1250
Type of Machine	Moveable Type

Detailed Images

Screw rod

Name: Screw rod of the silicone extruder

Brand: Huitian

Original: China

Patent part of Tianjin Huitian(our factory)

The type of screw is unequally spaced and unequally deep, single screw thread. When the compression ratio is 2.5:1, it can extrude all kinds of soft and hard silicon rubber with the degree of 30 to 80 (Shore A hardness)well.
