trucks tanker truck 20m3 water tank truck for sale in kenya from china

Supplier: Hubei Xindongri Special Vehicle Co., Ltd.
Region: Hubei, China
Contact: Mr Eric Shen
Price: $19500.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

Place of Origin:	Hubei China;	Emission Standard:	Euro 3;
Tiye tire:	7.00-16R;	Product name:	Water Sprinkler Truck;
After-sales Service Provided:	Video technical support,Online support;	Tank material:	Carbon Steel. Stainless Steel;
Tank Volume:	8001 - 10000L;	Brand Name:	Dongfeng;
Drive Wheel:	4x2;	Payment Terms:	L/C,D/P,T/T;
Dimensions (L x W x H) (mm):	7000 x 2120 x 2600;	Engine Capacity:	4 - 6L;
Packaging Detail:	NUDE;	Gross Vehicle Weight:	8495;
Wheelbase:	3800(mm);	After-sales Service Provided:	Engineers available to service machinery overseas;
Transmission Type:	Manual;	Sprinkling width:	Sprinkling Width>14m;
Drive type:	4x2;	Chassis brand:	Dongfeng;
Supply Ability:	1000 Unit/Units per Month;	Condition:	New;
Certification:	ISO9001;	Warranty:	1 Year;
Port:	Shanghai port;	Sprinkling Area (m):	> 16 m;
Cab:	Single;	Fuel:	Diesel;
Applicable Industries:	Machinery Repair Shops,Manufacturing Plant,Energy & Mining;

Product Description

China Factory 8-10cbm dongfeng manual water tank truck for sale in dubai

Specification of DF Sprinkler Truck / Watering Cart DLK
Item	Specification	Item	Specification
General
Truck Name	Sprinkler truck / Watering Cart	Overall Dimension (mm)	7000×2120×2600
Truck Brand	Dongfeng	Gross / Curb Weight (kg)	8495 / 3800
Truck Model	DFA1080SJ11D3	Approach / Departure Angle (°)	20 / 10
Max. Speed (km/h)	90	Front / Rear Overhang (mm)	1210 / 1990
Chassis
Chassis Brand	DF	Chassis Model	EQ1108KJ
Wheel Base (mm)	3950	Leaf Spring	8/10+7; 11/9+7
Traction System	4 x 2	Quantity of Axles	2
Cab Capacity	1+1	Front / Rear Axle Load (kg)	3390 / 5105
Transmission	manual	Front / Rear Wheel Tread (mm)	1770 / 1586 1831 / 1640
Tyre Model	9.00-20	Quantity of Tyre	6
Engine (Motor)
Brand	DF	Type of Fuel	Diesel
Model	CY4102-CE4B	Displacement (ml)	3856
Max. Power (KW/hp)	125 / 170	Emission Standard	Euro 3
Cylinder Stator	4, all cylinders arranged vertically in line	Max Torque (N.m)	420
Quantity of Valves Per Cylinder	4	Maximum Torque Speed (rpm)	1300-1500
Cylinder Diameter × Stroke (mm)	102 x 118	Motor Rated Rotating Speed (rmp)	2800
Full Load Minimum Fuel Consumption Rate (g/KW.h)	≤200	Air Intake Form	inter-cooling, water cooling
Compression Ratio	17 : 1	Noise From 1 Meter	≤114dB
Motor Net Weight (kg)	430	ABS	yes
Equipments
Tank Capacity (L)	8000-10000	Tank Material	4-6mm carbon/stainless steel
Water Pump Flow(m³/h)	60	Watering Width(m)	≥14
Vertical Suction (m)	≥6	Water Cannon Covering Range (m)	≥23
Priming Time (min)	<5	Lift of Pump (m)	45
Water Inlet Diameter (mm)	40
REMARKS: 1. Equipped with high power self-suction water pump that characterized by high-pressure and fast speed suction. 2. Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform. 3. The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30m. 4. Equipped with fire coupling, flow valves, filter screen and water level gauge. 5. According to customers’ request, the crane, high working platform and spraying machine also can be equipped. 6. Mainly used for washing on urban roads, watering and greening on trees, green belts and lawn and dust full of construction sites. And also used for drinking water delivery and fire fighting function etc.
NOTE: 1. Any part can be customized depending on customers' demand. 2. 12 months whole vehicle warranty 3. We could support you original spare parts. Besides, we can give assistance in the following days by email or telephone. If necessary, our outwork engineer could go for technical assistance.
