Hot Sale Sunda New Energy First Step Crusing Range 520KM 11M Pure Electric Double-decker City Bus

Product details
Transmission Type:Automatic;Seats:> 60;
Dimensions (L x W x H) (mm):12000*2550*3335;size(mm):10800*2550*4180;
Charging rate:1C;Cruising range:520km;
Steering Position:RHD;Product name:Electric Double-decker City Bus;
Payment Terms:L/C,T/T;Max Speed:51 - 70 km/h;
Voltage platform:268.8V;Packaging Detail:Marine corrosion protection;
Place of Origin:Sichuan China;Supply Ability:1000000 Piece/Pieces per Month;
Brand Name:Sunda;Nominal capacity:100Ah;
Number of guests:79,87;Port:Shenzhen;
Maximum total mass (kg):17900;total storage capacity:287.96kwh;
Maximum speed (km/h):69;Fuel Type:Electric;

Hot Sale Sunda New Energy First Step Crusing Range 520KM 11M Pure Electric Double-decker City Bus

Product Description



Model information

Announcement model

CDK6110CSBEV

Fuel type

Pure electric





Announcement batch

309 batches

Recommended directory

Batch 7 in 2018





Exempt catalog

19th batch













Basic parameters

Body size length * width * height (mm)

10800*2550*4180





Curing quality (kg)

12400,11710

Approach / departure angle(.)

8.5/11





Maximum total mass (kg)

18000

Minimum turning diameter (m)

22





Front overhang / rear overhang (mm)

2500/2100

Wheelbase (mm)

6200





Track front/back (mm)

2120/1890

Number of guests

86,96





Maximum speed (km/h)

69

Step type

First step



Three-electric system

Electric drive system

Permanent magnet synchronous motor TZ420XSCD1, rated power 100kw, peak power 250 kw





Energy storage system

Lithium iron phosphate battery, total storage capacity 287.96kwh, energy density: 141.8wh/kg





Voltage platform

531.3V

Nominal capacity

542Ah





Cruising range (equal speed method)

520km

Charging rate

1C





Charging time

1.5h/526V

Charging mode

Slow charge


Detail image





Company Information





Sunda New Energy is committed to research and develop the power battery Pack of electric vehicle , electric vehicle charging piles and distribution of new energy vehicles. We are the general agent of SHUDU Bus Company in both Hunan Province and South -East Asia. Sunda New Energy Huaihua Factory has an annual output of 20,000 sets of charging piles and 1GWH battery PACK, which is also a state-level high technology enterprise and a provincial green factory. We has successfully passed ISO14001, ISO9001, IATF16949 quality management system certifications. Meanwhile,we possess the independent intellectual property rights and the ability of sustainable research and development.And we built a long-term strategic cooperation with Central South University.



Certifications



FAQ



1.Q:Where can I get the price?



A:We usually quote within 24 hours after we get your inquiry.if you are very urgent to get the price,please call us or tell us in your inquiry priority.



2.Q:how can I get a sample to check your quality?



A:After price confirmation,you can require for samples to check our quality.



3.Q:What about the lead time for mass production?



A:It depends on your order quantity and the season you place the order.



4.Q:What is your team for payment?



A:We accept T/T,L/C,Paypal, Western Union,Money Gram,Ali Express,Cash,etc.



5.Q:What is accepted payment currency?



A:We accepted USD,EUR,CAD,AUD,HKD,GBP,JPY,NZD,SGD,CHF,THB,etc.
