Sunda 12 meters hybrid bus with diesel engine and battery pack city bus tourist bus

Product details
Port:shenzhen;Voltage platform:309.12;
Maximum total mass (kg):7500;total storage capacity:62.44kwh;
Nominal capacity:202Ah;Packaging Detail:Marine corrosion protection;
Payment Terms:L/C,T/T;Charging rate:1C;
Supply Ability:10000000 Piece/Pieces per Month;Charging time:1.5h(350V);
Number of guests:19;Cruising range:200km;

Sunda 12 meters hybrid vehicle with engine and power battery/ city bus/ tourist bus



Product Description



Model

information

Announcement model

CDK6126CBEV3

Fuel type

Pure electric



Announcement batch

307 batches

Recommended

directory

Batch 5 in

2018



Exempt catalog

Eighteenth batch









Basic

 parameters

Body size length * width * height (mm)

12000*2550*3185, 3020 (without air

conditioning)



Curing quality (kg)

12000,11400

Approach / departure

 angle(.)

7.5/7.5



Maximum total mass

 (kg)

17900

Minimum turning

diameter (m)

24



Front overhang /

rear overhang (mm)

2600/3200

Wheelbase (mm)

6200



Track front/back (mm)

2066/1870

Number of guests

90,96



Maximum speed

(km/h)

69

Number of guests

90,96



Step type

Secondary step

Maximum speed

 (km/h)

69

Three-electric system

Electric drive system

Permanent magnet synchronous motor

(double motor plus two-speed AMT) TZ350XSCD1,

rated power 90kw, peak power 140 kw



Energy storage system

Lithium iron phosphate battery in Ningde era,

 the total storage capacity is 241.96kwh,

energy density: 141.5wh/kg, 140.7 wh/kg



Voltage platform

598.92

Nominal

 capacity

404Ah



Cruising range

(equal speed method)

440km

Charging rate

1C



Charging time

1.5h/678.9V

Charging mode

Slow charge





Detail Images





Campany Information

    Sunda New Energy is committed to research and develop the power battery Pack of electric vehicle , electric vehicle charging piles and distribution of new energy vehicles. We are the general agent of SHUDU Bus Company in both Hunan Province and South -East Asia. Sunda New Energy Huaihua Factory has an annual output of 20,000 sets of charging piles and 1GWH battery PACK, which is also a state-level high technology enterprise and a provincial green factory. We has successfully passed ISO14001, ISO9001, IATF16949 quality management system certifications. Meanwhile,we possess the independent intellectual property rights and the ability of sustainable research and development.And we built a long-term strategic cooperation with Central South University.

Certifications



Our Factory



FAQ

1.Q:Where can I get the price?

A:We usually quote within 24 hours after we get your inquiry.if you are very urgent to get the price,please call us or tell us in your inquiry priority.



2.Q:how can I get a sample to check your quality?

A:After price confirmation,you can require for samples to check our quality.



3.Q:What about the lead time for mass production?

A:It depends on your order quantity and the season you place the order.



4.Q:What is your team for payment?

A:We accept T/T,L/C,Paypal, Western Union,Money Gram,Ali Express,Cash,etc.



5.Q:What is accepted payment currency?

A:We accepted USD,EUR,CAD,AUD,HKD,GBP,JPY,NZD,SGD,CHF,THB,etc.
