Crude drug Tray dryer & oven machine with high capacity

Supplier: Jiangyin Baoli Machinery Manufacturing Co., Ltd.
Region: Jiangsu, China
Contact: Mr TAO TAO
Price: $3000.00 /set
Min. Order: 1 set

Click here to contact

Product details

MOQ:	1 Set;	Condition:	New;
Model Number:	JB-B-O;	Line:	food, chemical and pharmaceutical;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Packaging Detail:	wooden packing for Crude drug Tray dryer & oven machine with high capacity;
Brand Name:	Jinbao;	Heating type:	steam/ electric;
Warranty:	1 Year;	Delivery Detail:	20-30 days;
Certification:	ISO CE;	Key word:	Tray dryer;
Supply Ability:	10 Set/Sets per Month oven machine;	After-sales Service Provided:	Engineers available to service machinery overseas;
Place of Origin:	Jiangsu China;	Material:	stainless steel;
Port:	Shanghai;

Crude drug Tray dryer & oven machine with high capacity

Main Usage
This machine is widely applied for the heating and dehumidifying of raw materials and products in the lines of pharmacy ,chemical , foodstuff , light industry , heavy industry etc .

Specialty
Great part of hot wind is circulated in the oven with high thermal efficiency ,less energy consumption , The oven is equipped by the adjustable air-distributing plates to utilize the forced ventilating to dry the target materials evenly , The whole machine runs in stable condition ,low noise , self-control temperature , easy installing and maintaining ,and wide application.

Technical Data

Model&Specif. \Tech.	dry amount eachkg	matched powerkw)	steam expend (kg/h)	heat dispelling area	wind m3/h	diff.in up & down temp.	collo-cate tray	Overall sizeL×W×Hmm	Weight kg	collo-cate pushcart
JB-A-	120	1.1	25	20	1400	±2	48	2430×1200×2430	1200	2
JB-A-	240	1.1	50	40	5200	±2	96	2430×2200×2480	1500	4
JB-A-	360	2.2	75	80	9800	±2	144	3430×2200×2620	2000	6
JB-A-	480	2.2	95	100	9800	±2	192	4460×2200×2620	2300	8
JB-B-O	30	0.45	6	5	3450		8	1370×1200×2200	800	1
JB-B-I	120	0.45	20	20	3450	±2	48	2300×1200×2200	1500	2
JB-B-II	240	0.9	45	40	6900	±2	96	2300×2210×2200	1800	4
JB-B-III	360	1.35	70	80	10350	±2	144	3300×2210×2200	2200	6
JB-B-IV	480	1.8	90	100	13800	±2	192	4460×2210×2200	2800	8
