ZIXU Free Shipping Wholesale Light Weight portable Pneumatic Dot Peen chassis Vin Number Marking Machine

Product details
Brand Name:ZIXU;Drive type:pneumatic;
Main Axle Rotational Speed:300time/s;Package Preview:https://sc01.alicdn.com/kf/HTB1RGA_JkSWBuNjSszdq6zeSpXa5.jpg_640x640.jpg;
Repeat accuracy:0.02-0.04mm;Certification:CE ISO9001 FDA;
Product name:VIN Number Marking Machine;Selling Units:Single item;
Single gross weight:15.0 KG;Key Selling Points:Long Service Life;
Model:ZX-PMK-G02;Place of Origin:Chongqing China;
Controller:7"LCD Controller/LCD;Dimensions:40*40*50cm;
Rated Power:300W;Colour:Custmization;
Machine Type:chassis VIn marking;Marking materials:above HRC60 need special stylus;
Marking area:50x20mm;Single package size:45X45X50 cm;
Feeding Height:30-350mm;Software:Insert ThorX7;
Milling Cutter Diameter:3mm;Condition:New;
After Warranty Service:Video technical support,Online support,Spare parts;Applicable Industries:Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Construction works ,Energy & Mining;
Packaging Detail:packaged by carton box;Weight:3.2kg;
Warranty:2 years;Local Service Location:Saudi Arabia,Russia,Japan,Australia,South Korea,Kazakhstan;
Marking Type:Pneumatic Handheld Portable Pneumatic Marking Machine;Showroom Location:Indonesia,India,Mexico,South Korea,Romania,Tajikistan;
Application:50x20mm;Engraving Speed:1-5 letters/second;
After-sales Service Provided:Free spare parts,Video technical support,Online support;

ZIXU Free Shipping Wholesale Light Weight portable Pneumatic Dot Peen Vin Number Marking Machine with OEM Service

Product Description

VIN Number Dot Peen Marking Machine Description

1. The machine is capable of marking on soft & hard components.

2. The machine can mark all metals such as Steel, Stainless Steel, Copper brass, Gold, Silver etc. Ideal for marking on hard plastics.

3. The machine can mark permanent Batch numbers, Serial numbers, Barcode scanned data, data from PLC, Date Codes, Month Codes, Year Codes, etc.

4. Pneumatic metal marking type.

Additional Information

1. Part Number: ZX-PMK

2. Material: Stainless Steel

3. Batteries Required: No

4. Shipping Weight: 48.5 pounds



Machine Parameter

VIN Number Dot Peen Marking Machine Parameter

Marking speed

2-5 characters(2x2mm)/s

Stroke Frequency

300times/s

Marking depth

0.01 to 2mm (depends on the different material)

Marking contents

Characters, alphanumeric, date, numbers, serial No, VIN code etc.

Stylus Pin Hardness

HRA92/HRA93

Marking area

80x40mm(customized accept)

Dimensions

45x45x55cm

Materials request

< HRC60 metallic and nonmetallic materials

> HRC60 need special stylus

Repeat accuracy

0.02-0.04mm

Power

300W

Work voltage

AC220V±10%/50HZ

Inputting air pressure

0.3 - 0.6Mpa

Connection

USB and RS-232

Controller

a. 7"LCD touch screen controller

b. windows 7 & windows XP

Power type

Pneumatic

Marking directions

up, down, left, right, and the circular arc surface marking

Gross weight

12kg

click here visit our shop directly now!!!

Click for More Information!!!



Application Area



Product Advantage

VIN Dot Peen Number Marking Machine Advantages

1.  The size is same as the phone, easy to carry.

2.  Will be suiting for outdoor and other places.

3.  For automobile beam, frame, engine, marking operation is especially convenient.



VIN Number Dot Peen Marking Machine's Marking Needle

1. High wear resistant,high frequency,strong intensity,long range, stable performance.

2. Adopt imported all-carbide crown/marking needle.

3. For metal parts below hardness HRC63 and hard non-metallic material.

4. Needle strength 30% higher than ordinary marking.



VIN Number Dot Peen Marking Machine High precision linear guides

1. Use high precision gap automatically fit.

2. Heat resistance,compressive.

3. Small sliding wear.

4. Long product service life.



VIN Number Dot Peen Marking Machine Swith Button

1. Use metal material for body.

2. Service life more than 10 millions times.

3. Durable in use.



VIN Number Dot Peen Marking Machine Free Items

Including two marking needles, pressure regulating valve, power line and one cable as shown in pic below.

Company Information

Why choose us?

1. Smart and portable,easy to carry for working on big parts like Automotive frame.

2. Numerous option for fonts,supporting edit fonts.

3. Marking depth is adjustable by controlling the marking pin.

4. Stable quality and can work continuously for the whole day.

5. Flexible configuration of various models of mark.

6. High speed operation, stable lasting.

7. Support line and dot marking.

8. Can be customized according to the customers’ requests.

 VIN Number Dot Peen Marking Machine Factory

Chongqing Zixu Machine Works is a professional engaged in marking machine design and industrial enterprises. Founded in 2006, covers an area of 2000 square meters. In annual production of 500 sets of laser marking machine, 500 sets dot peen marking machine and electric marking machine, more over 100000 pieces marking stylus.



Products are exported to all countries in the world,Such as the India, Spain, France, Germany, the United States, Brazil, South Korea and other more than and 30 countries.



After we continue to improve and perfect the product quality has been achieved CE, ISO9001, FDA, TUV certificate, won the domestic and foreign large number of customers favor and approval.

Contact us

We offer 24 hours online professional service, focusing here contact us directly now!!!

Vin Number Printing Machine Packing and Shipping

+
Delivery time3~10 days
Type of shippingExpress, Air and Sea
Terms of paymentT/T, credit card, western union, Paypal
Package size75x55x83cm
Gross weight22kg
