Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; | Overall lengthOverall width: | 14000mm; |
Warranty of core components: | 1.5 years; | Max. Lifting Capacity: | 100t; |
Showroom Location: | None; | Warranty: | 1 YEAR; |
Video outgoing-inspection: | Provided; | Local Service Location: | None; |
Product name: | 100 ton Mobile Crane; | Port: | Qingdao port, Shanghai port, Tianjin port, or others as request; |
Max. Lifting Height: | 78.1m; | Hydraulic Valve Brand: | -; |
Marketing Type: | Ordinary Product; | Packaging Detail: | ROLL shipment or Bulk break shipment..; |
Supply Ability: | 30.0 Set/Sets per Month; | Condition: | New; |
Overall Weight: | 46000kg; | Certification: | CE; |
Place of Origin: | China; | Hydraulic Pump Brand: | -; |
After-sales Service Provided: | No after-sales service,Field installation, commissioning and training,Field maintenance and repair service,Video technical support,Online support,Free spare parts; | Crane type: | Truck Crane Mobile Crane Hydraulic Crane; |
Hydraulic parts: | Telescopic Boom Mobile Crane Made; | Core Components: | OTHER; |
Application: | All-terrain Mobile Crane; | Feature: | Truck Crane; |
Machinery Test Report: | Provided; | Engine Brand: | -; |
UNIQUE SELLING POINT: | -; | Rated Lifting Moment: | 4320kN.m; |
Span: | 78.1m; | Rated Loading Capacity: | 100 ton; |
Hydraulic Cylinder Brand: | --; | Applicable Industries: | Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Construction works ; |
Overall length: | Overall length; | After Warranty Service: | Video technical support,Online support; |
Boom Length: | 56m; |
STC1000S Mobile crane uses electric proportional variable displacement piston pump to ensure high--accurate flow control, higher efficiency and energy saving. Jib mounting angles are 0°, 15°, and 30°, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency of the machine.
Powerful Lifting Capacity
The 100 ton Mobile crane has six-section boom of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 100t, full-extended boom length of 56m, jib length of 15.5m, max.lifting height including jib of 77.5m, reduce weight and improve safety significantly.
Efficient & Unique Hydraulic System
Self-developed dual-pump converging / diversion main valve is used. Converging flow of the single-action dual-pump ensures fast operation and high efficiency; combined-action dual-pump diversion system is applied to ensure stable controllability.
Excellent Traveling Performance
The first 100t-class crane use 4-axle chassis with overall weight of 46t, which is the lightest crane of similar class cranes; multiple braking modes and all axles steered design ensure more agile and reliable traveling performance; the use of tipping over early-warning technology guarantees high stable and safe operation.
Intelligent Electronic Control
Self-developed controller SYMC special for engineering machinery is configured. The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in real time.
The Load Moment Limiter
Equipped with the comprehensive intelligent protection system is used with accuracy within 5%. The adoption of comprehensive logic and interlock control system ensures more safe and reliable operation.
Comfortable
385/95R25 tyre is equipped which ensure a stable cross-country traveling performance. Sleeper is equipped in the operator's cab providing comfortable condition for the driver.
Low Fuel Consumption
The fuel consumption is 50L/100km which could low the cost of running and maintenance. It is the lowest compared to the same class crane.
Technical Data
Capacity |
Max. lifting capacity |
100t |
Dimensions |
Overall length |
14000mm |
Overall width |
2800mm |
|
Overall height |
4000mm |
|
Axles |
4 |
|
Axle distance-1,2 |
2080mm |
|
Axle distance-2,3 |
3925mm |
|
Axle distance-3,4 |
1500mm |
|
Weight |
Overall weight |
46000kg |
Front axle load |
22000kg |
|
Rear axle load |
24000kg |
|
Engine |
Model |
Cummins |
Rated power |
275kw/2100rpm |
|
Rated torque |
1550N·m/1100~1400rpm |
|
Emission standard |
Euro Ⅲ |
|
Traveling |
Max. traveling speed |
80 km/h |
Min.turning radius |
10.5m |
|
Min. ground clearance |
320mm |
|
Approach angle |
21° |
|
Departure angle |
19° |
|
Braking distance(30km/h) |
≤10 m |
|
Max. gradeability |
40% |
|
Fuel consumption per 100km |
≤ 50L |
|
Main Performance |
Min.lifting radius |
3m |
Boom section |
6 |
|
Boom shape |
U-shaped |
|
Max. lifting moment-Base boom |
3300kN·m |
|
Max. lifting moment-Full-extend boom |
1824kN·m |
|
Length-Base boom |
12.26m |
|
Length-Full-extend boom |
56m |
|
Length-Full-extend boom+jib |
71.5 /77.5 m |
|
Outrigger span(Longitudinal/Transversal) |
7.8×7.91m |
|
Jib offset |
0 ° 15 ° 30 ° |
|
Working Speed |
Max. single rope lifting speed of main winch(no load) |
|
Max. single rope lifting speed of auxiliary winch(no load) |
123m/min |
|
Full extend/retract time of boom |
480 / 500s |
|
Full raise/lower time of boom |
60 / 80s |
|
Swing speed |
0~1.6 r/min |
|
Aircondition |
HVAC in up cab |
Cooling and Heating |
