8 ton XGTL120(5016-8) electric internal climbing tower crane price

Supplier: Shanghai Vostosun Industrial Co., Ltd.
Region: Shanghai, China
Contact: Ms Wang Jing
Price: $36895.00 /set
Min. Order: 1 set

Click here to contact

Product details

Span:	50m;	Max. Lifting Height:	100.1M;
Section material:	Angle steel/Folding;	Payment Terms:	L/C,T/T,Western Union,MoneyGram,BANK OF KUNLUN;
Place of Origin:	Shanghai China;	Condition:	New;
Length:	50/45/40/35/30;	After-sales Service Provided:	Engineers available to service machinery overseas;
Rated Lifting Moment:	120 t.m;	Tip load:	1.6/2.2/2.8/3.5/4.4;
Application:	Construction;	Section size:	160016003000;
Packaging Detail:	ROLL shipment or Bulk break shipment. Standard packing, spare parts will put into the wooden cases then transport by the container, or as request, each machine and spare part will be matched with a nameplate in customer local language.;	Certification:	CE ISO;
After-sales Service Provided:	Video technical support,Field installation, commissioning and training,Field maintenance and repair service,Free spare parts,Online support,No after-sales service;	Rated Loading Capacity:	8t;
Port:	Qingdao port, Shanghai port, Tianjin port, or others as request;	Supply Ability:	50 Set/Sets per Month Stationary hydraulic concrete placing boom hg32;
Feature:	Tower Crane;	Applicable Industries:	Garment Shops,Building Material Shops,Construction works ;
Basic height:	28.1M;	Brand Name:	XCGM;
Warranty:	1 Year;

Product Description

Type	XGTL120(5016-8)
Basic height	28.1M
Max height	100.1M
Length	50/45/40/35/30
Max load	8t
Tip load	1.6/2.2/2.8/3.5/4.4
Section size	1600×1600×3000
Section material	Angle steel/Folding

XGTL120(5016-8)
Items	Mechanism	Speed(m/min)		Rope capacity	Motor(Kw)
Hoist mechanism	30JLF20A	2 multiplying power	0-80	550M >550M*	30
		4 multiplying power	0-40
Luffing mechanism	30JDF35B	≤3min			30
Slewing mechanism	JH08T6	0-0.7r/min			2×5.5
Travelling	RT	0-24m/min			2×5.2
Main Supply	380V(±10%)/50Hz*
Gross Power(Excluding climbing and travelling):71Kw

Product Advantages

1. The electronic control system adopts high-quality electrical components and low fault control design to ensure that the electrical control system is stable, reliable and has a long service life.

2. The main electrical control components use imported components to increase life and reliability. The control system has a high degree of automation, which facilitates the operation of the tower crane and the real-time understanding of the tower crane's various operating data, providing the driver with safe, reliable and simple operation.

3. The configuration has high-quality safety devices with high reliability and high precision ensures the safe operation of the tower crane.

4. The tower body is a standard piece section, which is convenient for transportation and high interchangeability. The boom has a combination of 30m, 35m, 40m, 45m, and 50m.

5. The driver's room is a space warehouse, independent side, good vision, spacious interior space, to create a comfortable working environment for the operator.
