Capacity (t/d): | 140; | Port: | Qingdao/Shanghai/Tianjin; |
Subsidence Area (m2): | 38.5; | Weight (kg): | 13862; |
Packaging Detail: | standard package; | After-sales Service Provided: | Engineers available to service machinery overseas,Free spare parts,Video technical support,Field installation, commissioning and training,Field maintenance and repair service; |
Tank Depth (mm): | 3000; | Motor Type: | AC Motor; |
Motor Power (kW): | 2.2; | Core Components: | Engine,Bearing,Gearbox,Motor,Gear; |
Brand Name: | HANFA; | Model: | NZSG-7; |
Motor Model: | Y112M-6; | Local Service Location: | Egypt,Canada,Turkey,United Kingdom,United States,Italy,France,Germany,Viet Nam,Philippines,Brazil,Peru,Saudi Arabia,Indonesia,Pakistan,Mexico,Russia,Spain,Thailand,Malaysia,Australia,Morocco,Kenya,Argentina,South Korea,Chile,UAE,Colombia,Algeria,Sri Lanka,Romania,Bangladesh,South Africa,Kazakhstan,Ukraine,Kyrgyzstan,Nigeria,Uzbekistan,Tajikistan; |
Condition: | New; | Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; |
Type: | Mining Thickener; | Production Capacity: | 5-1400t/d; |
Supply Ability: | 20.0 Set/Sets per Month; | Applicable Industries: | Construction works ,Energy & Mining; |
Showroom Location: | None; | Place of Origin: | Henan China; |
Marketing Type: | Hot Product 2019; | Machinery Test Report: | Provided; |
Warranty of core components: | 1 YEAR; | Tank Diameter (mm): | 7000; |
Video outgoing-inspection: | Provided; | Certification: | ISO, CE; |
Warranty: | 1 YEAR; | Steel Tank Weight (kg): | 8800; |
Technical Parameters
Model |
Tank Diameter (mm) |
Tank Depth (mm) |
Subsidence Area (m2) |
Capacity (t/d) |
Motor Model |
Motor Power |
Steel Tank Weight |
Weight (kg) |
NZSG-2.5 | 2500 | 1850 | 4.9 | 5 ~22.4 | Y90L-6 | 1.1 | 1000 | 2225 |
NZSG-3A | 3000 | 1800 | 7 | 5 ~23.3 | Y100L-6 | 1.5 | 1664 | 3168 |
NZSG-3 | 3600 | 1800 | 10.2 | 5 ~28.5 | Y100L-6 | 1.5 | 2097 | 3680 |
NZSG-5 | 5000 | 2956 | 16 | 16 ~90 | Y90L-4 | 1.5 | 5160 | 8031 |
NZSG-6 | 6000 | 2956 | 28.3 | 98 | Y90L-4 | 1.5 | 5769 | 9200 |
NZSG-7 | 7000 | 3000 | 38.5 | 140 | Y112M-6 | 2.2 | 8800 | 13862 |
NZSG-8 | 8000 | 3318 | 50.2 | 185 | Y132S-6 | 3 | 12966 | 19158 |
NZSG-9 | 9000 | 3376 | 63 | 210 | Y132S-6 | 3 | 15418 | 21733 |
NZSG-12 | 12000 | 3600 | 113 | 370 | Y132S-6 | 3 | 25589 | 34823 |
NZSG-15 | 15000 | 3600 | 176 | 580 | Y132S-4 | 5.5 | 35800 | 54315 |
NZSG-18 | 18000 | 4400 | 255 | 960 | YCT200-4B | 7.5 | 52485 | 73588 |
NZSG-20 | 20000 | 4400 | 315 | 1400 | YCT200-4B | 7.5 | 59365 | 76312 |
ADVANTAGES
Out overflow weir instead of inner overflow weir increases the sedimentation area and not easy to block;
Oblique feeding instead of horizontal feeding solves the blockage problem;
A tranquil flow device reduces material flow rate, so that the overflow becomes more uniform with lower turbidity.
Product Structure
The vertical axis rotates driven by motor, and pulp by feeding device flows into the tank center feed mixing barrel.Solid material in the bottom of the tank by the scraper moves out of center; clarified overflow through the tranquil flow device flows out from the ring external overflow weir.
