Warranty: | 1 Year; | Supply Ability: | 5000 Piece/Pieces per Month; |
Wave form: | Modified Sine Wave Power Inverter; | Rated power: | 1500W; |
Place of Origin: | Zhejiang China; | Package Preview: | ; |
Application: | Off-grid System; | Brand Name: | SOLARVERTECH/OEM; |
Packaging Detail: | Exact overall dimension and mounting chart, make the installation more accurate and convenience for shipping.; | Port: | shanghai/ningbo; |
Package: | Paper Carton; | OEM: | Accept OEM; |
Payment Terms: | T/T,Western Union,MoneyGram,PayPal; | Frequency: | 50/60 HZ; |
Model Number: | NM1.5K; |
Solarway is a professional off-grid power inverter supplier, is a sino-german joint venture, mainly engaged in off-grid power inverter/MPPT and PWM controller, research and development, manufacturing and sales, we can provide customers with off-grid power INVERTER OEM and ODM. The factory is located in Jiaxing, Zhejiang Province, China. We have R & D Center and After-sales Service Center in Beijing, China and Leipzig, Germany.
MODEL | NM1.5K-112 | NM1.5K-124 | NM1.5K-148 | NM1.5K-212 | NM1.5K-224 | NM1.5K-248 | ||
Output | AC Voltage | 100/110/120VAC | 220/230/240VAC | |||||
Rated Power | 1500W | |||||||
Surge Power | Load 120~150%(3min.);3000W(3sec.;resistive) | |||||||
Waveform | Modified Sine Wave | |||||||
USB port | 5V 2.1A | 5V 2.1A | ------ | 5V 2.1A | 5V 2.1A | ------ | ||
Input | DC Voltage | 12VDC | 24VDC | 48VDC | 12VDC | 24VDC | 48VDC | |
Voltage Range | 10.5~15VDC | 21~30VDC | 42~60VDC | 10.5~15VDC | 21~30VDC | 42~60VDC | ||
Efficiency(Typ.) | 89%~93% | |||||||
Remote Control | Function(optional) | |||||||
Protection | BAT.Low Alarm | 10.5±0.5VDC | 21±1.0VDC | 42±2.0VDC | 10.5±0.5VDC | 21±1.0VDC | 42±2.0VDC | |
BAT.LOW Shutdown | 10±0.5VDC | 20±1.0VDC | 40±2.0VDC | 10±0.5VDC | 20±1.0VDC | 40±2.0VDC | ||
Over Load | Shut down output voltage, restart to recover | |||||||
Over Voltage | 15.5±0.5VDC | 31±1.0VDC | 62±2.0VDC | 15.5±0.5VDC | 31±1.0VDC | 62±2.0VDC | ||
Over Temperature | Shut down output voltage, recover automatically after temperature goes down | |||||||
Output Short | Shut down output voltage, restart to recover | |||||||
DC Input Reverse Polarity | By fuse | |||||||
Earth Fault | Shut off o/p when the load has electrical leakage | |||||||
Soft Start | Yes,3~5 Seconds |
1.Q:Do you have your own factory?
A:Yes, we are professional manufacturer mainly in power inverter for many years. Our facory is located in Jiaxing, Zhejiang, China.
..............................................................................................................................................................
2.Q:What kind of certification you have?
A:ISO9001,CE,ROHS and so on.
Our products could pass different labor testing according to different countries' requirements.
..............................................................................................................................................................
3.Q:Where we can use the system?
A:You can use the system for home, for power station, for lighting system and so on, wnere the grid power is expensive.
............................................................................................................................................................
4.Q:How about your warranty?
A: We provide 1.5 and 3 years warranty for different products and whole life technical support.
.............................................................................................................................................................
5.Q:Competitive Price
A:All of our products are produced by our own factory. So the price is very copetitive.
.............................................................................................................................................................
6.Q:How to do the installation?
A: This portable solar system installation is very simple, only need to connect solar panel with controller, and push ON/OFF button, then it will start to work.
.............................................................................................................................................................
7.Q:24-hours online service
A: Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale.
