BAOTENG Factory Price UK waterproof plastic din rail electric terminal block

Product details
Voltage:800V;Brand Name:BAOTENG;
Packaging Detail:1.Normal Package: inner box +carton 2.Specific packaging can be made to order.;Single package size:4X2X1 cm;
Material:PA66;Wire Range:0.2-2.5 sqmm;
Conductor Size:11 - 20 AWG;Current:24A;
Selling Units:Single item;Number of Contacts:1 - 10;
Certificate:ISO9001/CE/ROHS;Packing:Box;
Item:din rail electric terminal block;Type:Screw;
Color:Gray / Customized;Single gross weight:0.001 KG;
Application:Wire Connecting;OEM/ODM/Sample:Offer;
Model Number:UK terminal;Place of Origin:Zhejiang China;

BAOTENG Factory Price UK waterproof plastic din rail electric terminal block

Bannar

Product Description





If you need more information about this product.Please CLICK HERE to contact our sales staff and we will provide you with more information about the products.And you can get sample soon.



Other Product

<<



UK series terminals block



 Specifications



1. Terminal: With general-purpose mounting feet, can be installed on tracks NS32 or NS35.



2. Closed bolt leading hole will not only facilitate operation of screwd-rivers, also prevent the bolt  from dropping out.



3. Electric potential distribution is realized by eitherconnecting central adaptor to the center of  terminal or inserting a side adaptor to the cone jack.



4. General auxiliaries, such as the end plate, segment spacer, and spacer, are attached for terminal with multiple sections.



5. The insulating shell is made if imported engineering plastic-polyamide Nylon 66(PA66). It is of high mechanical intensity, good electic property, and super flexibility.





6. Two ends on the top with white marking system to realize uniformed sign.



7. 15 years lifetime.



 8. OEM acceptable.





Model No.

UK 2.5B

Length/Height/Wide (mm)

42.5/42/6.2

Type

Screw Type Din Rail Terminal Block

Material

Flame resistant Nylon PA66, Nickel plated brass conductor

Rated Voltage/Current

800V/32A

Application

Wire Connecting

Cross section, solid/soft Cable

0.2-4 mm² / 0.2-2.5 mm²

Conductor Size

24-12 AWG

Mounting Type

DIN Rail NS 35

Standard

IEC 60947-7-1

LOGO

BAOTENLINK,  LOGO can be customized

Color

Grey, Blue, other color can be customized

Certification

CE/RoHS/CQC/ISO 9001

Name

Din Rail Electric Terminal Block
