'Hot product' 400-1500VA computer offline UPS with AVR, CE Approved

Product details
Port:Shenzhen port;Packaging Detail:Waterproof carton for computer offline UPS 400-1500VA with AVR;
Protection:Overvoltage;Output Voltage:220VAC/120VAC;
Type:Standby;Weight:5.42Kg;
Application:Computer;Payment Terms:L/C,T/T,Western Union;
Place of Origin:Guangdong China (Mainland);Brand Name:SRUPS;
Phase:Single Phase;Model Number:KS 500~1500VA;
Description:With AVR and CPU control;Supply Ability:10000 Piece/Pieces per Month;
Product name:computer offline UPS 400-1500VA with AVR, CE certificate;

Computer offline UPS  400-1500VA with AVR, CE certificate



Offline UPS Features:



1.Microprocessor control guarantees high reliability
2. Equipped with Boost and Buck AVR to stabilize input voltage
3. Built-in DC start function enables UPS to be started up without AC power supplied.
4. Smart RS-232 Communication Port with Free Download Software from the Internet.
5. Auto restart while AC recovery.
6. Compact size, light weight
7. Provides Modem/Phoneline Surge Protection.
8. Provides Overload Protection.
9. USB,  RJ 45/11 Optional



 Offline UPS Specification:

Product Series

Offline UPS

Model

KS 500/600

KS 1000/1200

Rated Power

Battery Power Backup (BPB)

500VA/300W

600VA/350W

1000VA/600W

1200VA/700W

Auto Voltage Regulator (AVR)

300VA

600VA

Input

Nominal Voltage

220VAC

Voltage Range

162~286VAC

Nominal Frequency

50Hz ±5%

Protection

Non-Fuse Breaker (NFB)

Output on Battery

Voltage

220Vrms ±10%

Frequency

50Hz ±1Hz

Output on Mains

A.V.R

176~266VAC

Battery

Type

Sealed Lead-Acid, Maintenance free (Panasonic)

Backup Time
(Full/Half Load)

10 min / 18 min

Recharge Time

4-6Hours max.

Overload Capability



Line Mode

BPB: 110% for 1 min, 130% immediate shutdown

AVR: NFB

Battery Mode

BPB: 110% for 10 sec., 130% immediate shutdown

LED indicators

Type

Red and Green LED

Status

Normal , Back up, Overload, Fault

Audible Alarm

Battery discharge

Beeping sound every four seconds after utility power fails.  Every second if battery approaches final discharge

Fault

Continuous beeping sound

Acoustic Noise

At 1 meter distance

< 45 dBA

Output Receptacles

Type

IEC320 or NEMA5-15R

BPB

3 pieces

4 pieces

AVR

2 pieces

Network Surge Protection Port

RJ45 Connector

Network (RJ45) or Fax/Modem (RJ11) compatible jacks

Communications

DB-9 Port

Environmental

Operating Temperature

0 ~ 40°C

Relative Humidity

20% ~ 90% Non-condensing

Weight

Net/Gross (kg)

4.8/5.3

8.3/10

Dimensions

W x D x H (mm)

425 x 400x 455

422 x  364x 475



















Sunray's Quality Policy



Qaulity is a system, quality is a project,it can contains all the activities of the whole factory,Suray's belief is "behave



ourseleves firstly, then keep the materials &produce in good level, finally assure the products's quality.everyactivity



effect the quality, so every one is the QC staff in factory.



All the running of Sunray Company is compliant with the ISO9001-2008 and ISO 14001-2004



What are you waiting for? pls no more hesitate to give us an  inquiry now!





Production Machinery:
Machine NameBrand & Model No.QuantityNumber of Year(s) UsedCondition
Wave Crest Soldering MachineFM-35025Acceptable
Chip Surface Mount MachineSM45115Acceptable
Reflow Soldering MachineRD-RF-8820PC-C15Acceptable



+
Testing Machinery:
Machine NameBrand & Model No.QuantityNumber of Year(s) UsedCondition
OscilloscopeTDS-2014C, TDS-340, DSO-X184Acceptable
Data Acquisition / Switch UnitsAgilent & 34970A24Acceptable
Manufacture Defects AnalyzerTR518FE23Acceptable
Temperature & Humidity Programmable ChamberSANMON12Acceptable
DC Power SupplyGPC-6030D124Acceptable
R / RCD Load3KM12Acceptable
Drop TesterZH-AS-10012Acceptable
Vibration Testing MachineZH-52012Acceptable
AC Standard MeterPF2010S12Acceptable







Why choose us?


1. 11 years gold credit supplier on Alibaba.

2. 13 years UPS and Power Inverter export experiences.

3. 14 years UPS and Power Inverter manufacturer experiences.

4. 13years of high-level OEM experience.

5. 5 production lines

6. 400 employees.

7. 10,000 square meters factory size (Sq.meters)

8.  80,000pcs monthly capacity

9. Export percentage: 90%

10. Hi-tech advanced R&D team with 32 senior engineers .

11. Certifications--applied with CE,SONCAP, ISO 9001, ISO14001 etc

12.Quality guarantee—warranty.
