product name: | Thread rolling die | usage: | External thread forming |
Warranty: | 1 | pack: | wooden box |
Finish: | Bright (uncoated) | Packaging Details: | wooden box |
Custom Support: | OEM, ODM, OBM | Supply capacity: | Thread rolling die factory 10,000 sets per month |
payment terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram | Certification: | International Organization for Standardization |
Minimum order quantity: | 1 set | Advantage: | Abrasion resistance |
port: | Ningbo Port | standard: | International Organization for Standardization |
Mold Type: | Thread rolling die | hardness: | HRC60-67 |
place of origin; place of origin: | China | Material: | Cr12MoV/SKH9/M2 |
Certificate: | ISO9001:2008 | | |
Product Description
Cylindrical thread rolling dieUsing a process with two or three rolling dies, the workpiece is usually placed on a support blade. At least one (1) rolling block has a feed motion to perform the forming process. At the same time, the mold and the workpiece are rotated synchronously in contact, and the contour will be formed.
Feed rolling
Feed thread rolling is based on one parameter: workpiece lead = die lead. This results in a synchronized rotational movement
part and death. No axial movement occurs. The necessary rolling force is defined by the thread diameter and length.
Always use thread rolling through feed when the workpiece contour is longer than the maximum length. Roll width.
There are 4 different types of through dies:
1.Ring Die: A grooved die without any lead. The lead angle is created by the rotation of the mold.
2.Speed up tooling: increase productivity.
3.Spiral slow feed die: reduce power requirements,
4.Continuous Rolling: Suitable for automatic feeding machines.
How to Order Cylindrical Thread Rolling Dies
Feed straightAperture (d):
Outer Diameter (D):
Thickness (T):
Keyway Depth (E):
Keyway Width (F):
Thread type: (such as M8*1.25,1''-8UNC...)
Full Thread Head Bolts
Full Thread Headless Bolts
Partially threaded bolts
Please specify if it is used for B7 material or wind power with special design.
VIEW MORE
