Wincoo DC inverter plasma cutting machine CUT-40 WELDER electric welding machine cutting machine

Supplier: Wincoo Engineering Co., Ltd.
Region: Jiangsu, China
Contact: Mr Jacky Nie
Price: $157.00 / 1 - 99 sets
$137.00 / >=100 sets
Min. Order: 1 set

Click here to contact

Product details

Dimensions (LxWxH):	430x250x300mm	place of origin; place of origin:	Jiangsu, China
Supply capacity:	3000 sets per month	Customization support:	OEM,ODM,OBM
brand:	win cool	model:	LGK-40
Packaging Details:	carton	Cutting thickness:	0-30mm
stage:	Simplex	Warranty:	1 year
Cutting material:	metal stainless steel carbon steel	weight:	15 kg
port:	Shanghai	application:	Industrial Metal Cutting
Cutting method:	air plasma cutting	Key words:	Cutting Machine
Rated output current:	40	Package preview:
product name:	Air plasma cutting machine	Cutting method:	plasma air
payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram

Product overview

LGK series frequency conversion air plasma cutting machine

-Small size, light weight, simple installation and easy operation;
- Good cutting performance and high cutting efficiency;
-The output current is continuously adjustable, and the working performance is excellent;

- Welding stainless steel, carbon steel, cast iron, steel and other alloy materials
-Products are widely used in petrochemical, pharmaceutical, electric power, cement, metallurgy, mining and other industries

List of functions

Model	LGK40	LGK60	LGK100	LGK120
Input voltage (V)	AC220+10%	AC380+10%	AC380+10%	AC380+10%
Frequency (Hz)	50/60	50/60	50/60	50/60
Rated input current (A)	25	15	25	29.5
No-load voltage (A)	240	270	300	308
Rated output current (A)	15-40	20-60	5-100	5-120
Rated output voltage (V)	96	104	120	128
load sustainability	60%	60%	60%	60%
No-load loss (W)	40	40	80	80
efficiency(%)	85	85	85	85
power factor	0.93	0.93	0.93	0.93
Insulation class	Second	Second	Second	Second
IP rating	twenty one	twenty one	twenty one	twenty one
Air pressure (Kg)	4.5	5	6	6.5

product specification

product configuration

Company manufacturing center

showroom

welding station

test

to assemble

load test

load testing machine

aging test

High and low temperature tester and multi-function test center

finished product

Package

1. Who are we?We have 3 joint venture factories in China with a total area of about 10000 square meters and more than 150 employees. we provide
MMA/ARC welding machine, MIG/MAG welding machine, TIG welding machine, air compressor built-in plasma cutting power supply.

2. What do we manufacture?We mainly manufacture MMA Welders Inverter Welders from 100 Amp to 500Amp (DIY or Industrial use). TIG welders from 150Amp to 300Amp, (DC or AC/DC). MIG/MAG welders from 120Amp to 500A, (gas or no gas). Air plasma cutters from 40Amp to 120Amp, (Pilot Arc or High Frequency Pilot Arc).

3. How can we guarantee the quality?We can provide 12 months warranty for the whole machine, 18 months for the motherboard, f. At the same time, we provide lifelong online operation guidance and troubleshooting technical support.

4. How to place an order? I have not done business with you guys before, how can I trust your company?We are able to provide online demonstrations to show performance before you make purchases, online video demonstrations during production and packaging, and online technical support after sales.

You can place an order online through Alibaba, which is safe for your money.

5. How to test?

We entrust your third party or SGS or your friends to inspect before delivery.5. Why choose us?OEM/ODM is available. Small order is acceptable, even 1 piece. Fast delivery available within 15 days

12-month machine warranty, 18-month motherboard warranty, lifetime technical support and after-sales service

Have a strong willingness to develop local agency or dealer brand

Provide online demonstration before order, online video during production and packaging, and after-sales video support.

Free cover design service available (private label)
