UBNT LOCO M2/locom2 300M High Power Wireless Bridge 8.5G/5GHz Outdoor Monitoring Engineering CPE Bridging

Product details
port:szpower supply:48V POE power supply
brand:UBNTPackage preview:
product name:Leco M2/ Lekom 2type:300Mbps wifi bridge, enterprise wireless access point
Packaging Details:There are new ones in the box.Origin:Guangdong, China
model:Leco M2/ Lekom 2Maximum power:23 decibels
payment terms:L/C, Western Union, D/P, T/T, MoneyGramBuilt-in Antenna:8dBi*2
application:outdoor, webcamSupply capacity:100 pieces per week

UBNT LOCO M2/locom2 300M high-power wireless bridge 8.5G/5GHz outdoor monitoring engineering bridge cpe

describe
M2 is a high-power industrial 2.4G outdoor CPE, adopting the next generation 802.11b/g/n Wi-Fi standard, combined with 2.4G 300Mbps high speed, equipped with 2 10/100M LAN ports, the Ethernet data rate is 2 times faster than ordinary CPE times, it enables more than 50 end users to access it to enjoy seamless HD movies, streaming media, online gaming, wireless security and other bandwidth-intensive tasks. It uses air as the medium of network data transmission to realize remote point-to-point or point-to-multipoint connections. Support 3KM transmission distance, bi-directional traffic up to 140M. With intelligent web page management, it can be paired automatically.







Loco M2 - Specifications

Locan 2
aspect 161 x 31 x 80 mm (6.31 x 1.22 x 3.15 inches)
weight 180 g (6.35 oz)
Power supply (PoE) 24V, 0.5A 24V, 0.5A
maximum. Power Consumption 5.5W 5.5W
power method Passive PoE (pairs 4, 5+; 7, 8 return)
working frequency 2412-2462 MHz
get 8.5 dB
Network Interface (1) 10/100 Ethernet port
Processor Specifications Atheros MIPS 24Kc, 400MHz
memory 32MB SDRAM, 8MB Flash
frequency 2.4GHz
cross polarization isolation 20 dB minimum
maximum. VSWR 1.4:1
beam width 60°(horizontal polarization)/60°(vertical polarization)/60°(elevation angle)
polarization bilinear
shell outdoor UV stabilized plastic
Install Pole Mount (Kit Included)
Operating temperature -30 to 75°C (-22 to 167°F)
Working humidity 5% to 95% non-condensing
