Mini CNC hydraulic shearing machine with simple operation Small stainless steel plate shearing machine price

Supplier: Maanshan Genuo Machinery Manufacturing Co., Ltd.
Region: Anhui, China
Contact: Mr Bryson Yuan
Price: $21000.00 / 1 - 4 sets
$16000.00 / 5 - 9 sets
$12000.00 / >=10 sets
Min. Order: 1 set

Click here to contact

Product details

Dimensions (lengthwidthheight):	330016101620	Key words:	Metal Steel CNC Cutting Machine
Warranty:	2 years	Core component warranty:	1 year
Core components:	Bearings, motors, pumps, gears, PLC, pressure vessels, engines, gearboxes	Material:	metal steel plate
Health status:	new	maximum. Cutting width (mm):	2500
Cutting angle:	0.5-3.5	maximum. Cutting thickness (mm):	4mm
Name:	Hydraulic gate shearing machine	Video outbound inspection:	if
Back gauge stroke (mm):	20 - 600mm	Power (kW):	5.5kW
type:	Shearing machine	Packaging details:	Steel pallet and plastic covering
Weight (kg):	3500kg	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
Year:	2023	Showroom location:	Egypt, Canada, United Kingdom, United States, Peru, Mexico, Russia, Argentina, Australia, None
Automatic level:	Fully automatic	color:	Require
Place of origin:	Anhui, China	Main selling points:	competitive price
brand:	guenot	Cutting thickness:	0-30mm
Mechanical test report:	if	Package preview:
brand:	guenot	Voltage:	220V/380V/400V
port:	Shanghai	Shear angle:	2
application:	Industrial metal cutting	Throat depth (mm):	100mm
Applicable industries:	Building materials stores, machine repair shops, manufacturing plants, print shops, construction engineering, energy and mining	Blade length (mm):	3400mm
Cutting materials:	Metal stainless steel carbon steel	Marketing type:	New products for 2023
Supply capacity:	50 sets per month

Product Description

Technical specifications

Model	Shear thickness	Maximum cutting length	Adjustable range of shearing angle
HG-6x2500	0.5~6mm	2500mm	0.5~1.5°
HG-6x3200	0.5~6mm	3200mm	0.5~1.5°
HG-8x3200	0.8~8mm	3200mm	0.5~1.5°
Backgauge range	main strength	About weight	aspect *lengthwidthheight*
10~500mm	7.5kW	5500kg	3800mm1700mm1950mm
10~500mm	7.5kW	6500kg	4100mm1700mm2000mm
10~500mm	11 kilowatts	7000kg	4100mm1750mm2000mm
