Warranty: | 1 year | Unique Selling Points: | Low maintenance cost |
Mechanical test report: | if | Engine brand: | famous brand |
engine model: | 6CTA8.3-C190-2 | Package preview: | |
Place of origin: | China | Video outbound inspection: | if |
Hydraulic cylinder brand: | famous brand | Hydraulic valve brand: | famous brand |
Core component warranty: | 1 year | Supply capacity: | 99 units per month |
port: | Shanghai Port | Marketing type: | New products for 2022 |
Certification: | CE/ISO | Showroom location: | Egypt, Canada, Turkey, United Kingdom, United States, Italy, France, Germany, Vietnam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, India, Mexico, Russia, Spain, Thailand, Kenya, Argentina, South Korea, Chile, United Arab Emirates , Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Ukraine, Nigeria, Japan, Malaysia, Australia, Morocco |
Hydraulic pump brand: | famous brand | payment terms: | Letter of credit, wire transfer |
Maximum blade position angle: | 45° | Health status: | new |
Dimensions (length*width*height): | 8900*2625*3420mm | Applicable industries: | Hotels, clothing stores, building materials stores, machine repair shops, manufacturing plants, food and beverage plants, farms, restaurants, household, retail, food stores, print shops, construction projects, energy and mining, food and beverage stores, advertising agencies |
Maximum lift off the ground: | 450mm | Core components: | PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump |
weight: | 15400kg |
Basic specifications | ||
engine model | SC8D190G2B1 | |
Rated power/speed | 140kW/2300rpm | |
Dimensions (length x width x height) | 8900×2625×3470 mm | |
Working weight (standard) | 15400kg | |
Performance specifications | ||
driving speed, forward | 5,8,11,19,23,38km/h | |
Driving speed, reversing | 5, 11, 23 km/h | |
Traction(f=0.75) | 79KN | |
maximum. Gradeability | 20% | |
Tire inflation pressure | 260kPa | |
Working hydraulic pressure | 16 MPa | |
transmission pressure | 1.3~1.8MPa | |
operating instructions | ||
maximum. front wheel steering angle | ±50° | |
maximum. Front wheel tilt angle | ±17° | |
maximum. Front axle swing angle | ±15° | |
maximum. Balance box swing angle | 15 | |
Frame articulation angle | ±27° | |
minute. Use articulated turning radius | 7.3m | |
blade | ||
Maximum lift off the ground | 450mm | |
Maximum cutting depth | 500mm | |
Maximum blade position angle | 90° | |
Blade cutting angle | 28°—70° | |
circle reverse rotation | 360° | |
Moldboard width x height | 3965×610mm |
