Galvanized welded steel wire mesh roll machine

Supplier: Hebei Dapu Import & Export Trade Co., Ltd.
Region: Hebei, China
Contact: Ms Laura Lee
Price: $10000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Rated Capacity:	50-70kva*4/5/6/7pcs;	Primary Voltage:	380V/220V/415V/440V;
Mesh type:	Roll mesh;	Wire diameter:	0.4-2.5mm;
Longitude wire feeding:	From wire coils;	Wire material:	Galvanized wire/Stainless steel wire/Black wire;
Port:	Xingang Port, China;	Packaging Detail:	1. The main machine and auxiliary equipments will be with plastic package, spare parts in carton box. 2. The main machine will be fixed in the container by steel wire rope to make it stable.;
Supply Ability:	30 Set/Sets per Month Wire panel mesh electrode welding machine;	Place of Origin:	Hebei China;
After-sales Service Provided:	Free spare parts,Field installation, commissioning and training,Field maintenance and repair service,Online support,Video technical support;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,Cash;
Dimensions:	2.51.81.6m;	Cooling system:	Air or water;
Brand Name:	DAPU;	Mesh width:	Max.2.5m;
Rated Duty Cycle:	10%;	Mesh length:	Max.50m;
Warranty:	2 Years;	Usage:	roll mesh machine;
Mesh size:	1/4",1/2",1",2",3",4";	Cross wire feeding:	From wire coils;

Galvanized welded steel wire mesh roll machine

Technical Parameters

Type	DP-DNW-1	DP-DNW-2	DP-DNW-3
Wire diameter	0.4-0.65mm	0.65-1.8/0.8-2mm	1.0-2.2/1.2-2.5mm
Aperture/pitch	1/4", 1/2"	1/2",1",2",3",4"	1",2",3",4"
Mesh width	Max.1.2m,1.5m,2m	Max.1.2m,1.5m,2m	Max.1.2m,1.5m,2m,2.5m
Motor	2.2kw	2.2kw;4kw	2.2kw;4kw
Welding speed	Max.75 rows/min	Max.120-180 rows/min	Max.80-120 rows/min
Transformer	50kva*3	60kva*4/5/7	60kva/70kva*5/6/7/8pcx
Weight	1.5T	2T;2.5T	2T;2.5T;3T;3.5T
Attentions:we can design the machine according to your wire diameter,mesh hole size and so on.

Product Display

Product Details

Auxiliary Equipment

Packing&Shipping

Certifications

Company Profile

FAQ

Q:Where is your factory located?

A: Our factory is located in Anping county, Hebei Province of China. The nearest airport is Beijing airport or Shijiazhuang airport. We can pick you up from Shijiazhuang city.

Q: How many years are your company engaged in the wire mesh machines?
A: More than 25 years. We have our own technology develop department and testing deparment.

Q: Can your company send your engineers to my country for machine installation, worker training?
A: Yes, our engineers went to more than 100 countries before. They are very experienced.

Q: What's the guarantee time for your machines?
A: Our guarantee time is 2 years since the machine was installed in your factory.

Q: Can you export and supply the customs clearance documents we need?
A: We have much experience for exporting. And we can supply the CE certificate, Form E, passport, SGS report etc, your customs clearance will be no problem.
