Port: | Ningbo/Shanghai; | Place of Origin: | Zhejiang China; |
guns: | one; | Feature: | charging pile; |
MOQ: | 1pcs; | Model Number: | KYCP-AC-15KW; |
Quality: | GOOD; | Brand Name: | KAYAL; |
Packaging Detail: | export standard package or according to customer's requirement...; | Output power: | 30kw/45kw/60kw/75kw/90kw/120kw/150kw; |
Cable Length: | 5m; | Supply Ability: | 2000 Set/Sets per Month; |
Style: | electric car charger; | Protection Level: | IP54; |
Input voltage: | 380V/AC 15%; | Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; |
Name: | EV charger; |
Overview
Product number | KECP-DC-7KW | KYCP-DC-15KW | KYCP-DC-20KW | |
Detailed specifications | rated power | 7KW | 15KW | 20KW |
Charging equipment | User Interface | Digital tube, LED | ||
Installation method | Portable | |||
Way of routing | After going in and out | |||
Equipment size | 345*175*265 | 540*375*195 | 540*375*195 | |
Input voltage | AC220V±20% | AC380V±20% | AC380V±20% | |
Input frequency | 45~65Hz | |||
The output voltage | 200V-450V | 200V-750V | ||
Single gun output current range | 0-15A | 0-20A | ||
The output voltage | 250V-750V | 200V-750V(constant power) | 200V-750V | |
Single gun output current range | 0-11A | 0-37.5A | 0-37.5A | |
Cable length | 5m (gun line 2m) | |||
Measurement accuracy | Level 0.5 | |||
Current limit protection value | ≥110% | |||
Voltage regulation accuracy | ≤±0.5% | |||
Steady flow accuracy | ≤±1% | |||
Ripple coefficient | ≤±0.5% | |||
effectiveness | ≥94.5% | |||
Power factor | ≥0.99 (50% load or more) | |||
Harmonic content THD | ≤5% (50% load or more) | |||
HMI | LED indicator | |||
Charging mode | Automatic charging | |||
payment method | no | |||
Communication Interface | no | |||
Executive standard | GB\T 20234, GB/T 18487, GB/T 27930, NB\T 33008 | |||
security function | Overvoltage protection, undervoltage protection, overload protection, short circuit protection, grounding protection, over temperature protection, low temperature protection, leakage protection | |||
Operating temperature | -25°C~+50°C | |||
Working humidity | 5%~95% non-condensing cream | |||
Working elevation | <3000m | |||
Protection level | IP20 | |||
cooling method | Air cooled | |||
Noise control | ≤55dB | |||
MTBF | 100,000 hours |
parameter | Min | Type | Max | Unit |
range of working temperature | -40 | 25 | 85 | ℃ |
Operating humidity range | 20 | 25 | 95 | RH% |
Altitude | 2000 | m | ||
Atmospheric pressure | 70 | 106 | Kpa | |
Heat dissipation method | Air cooled |
Installation environment requirements
Ensure that the input yellow PE line is grounded reliably;
It is forbidden to use in an environment with rain;
Keep away from flammable, explosive and corrosive sources;
Avoid steam and dust;
Keep away from electromagnetic interference sources;
Keep away from the heat source and fully consider the space around the pile to facilitate heat dissipation.
