30mm insulation white line shaft 9mm rotary potentiometer

Supplier: Huizhou Hong Yuan Electronic Technology Co., Ltd.
Region: Guangdong, China
Contact: Ms Rita Yan
Price: $0.18 / >=500 pieces
Min. Order: 500 pieces

Click here to contact

Product details

Rotation life:	10000cycles;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,Paypal;
Slider noise:	Less than 100mV;	Supply Ability:	5000 Piece/Pieces per Day;
Model Number:	RV9022NO PA30;	Insulation resistance:	Min:100MΩ at 250V DC;
Rotation stopper strength:	5.0Kgf.cm;	Port:	ShenZhen;
Technology:	Carbon Film;	Packaging Detail:	Plastic tray+carton;
Number of click:	Center click or 11clicks or 41clicks;	Delivery Detail:	20~25days;
Total rotation angle:	280°;	Withstand Voltage:	1 minute at AC 300V;
Rated Power:	0.025W~0.05W;	Resistance Tolerance:	20% / 10%;
Brand Name:	HongYuan;	Rotational torque:	10 ~200gf.cm;
Operating Temperature:	-20~+70;	Place of Origin:	Guangdong China;
Type:	Rotary Potentiometer;	Resistance:	B100K;
Total resistance:	500Ω~2M;	Max. Operating Voltage:	AC 50V;
Residual resistance:	Max :20Ω;

30mm insulation white line shaft 9mm rotary potentiometer

Product Description

Company Information

HongYuan Electronic Technology Co.,Ltd is located in GuangDong with convenient traffic, more than 100 outstanding productive staff. We are manufacture and specialized in development,manufacture and selling products of rotary switch,rotary Potentiometer,rotary encoder,slide switch ,toggle switch ,DC jack ,Micro switch ,Tact switch and so on . which are widely applied to home application,digital camera,car audio system,sound console desk,musical instrument,computer and other IT prodcuts.Our products are mainly exported to oversea markets .
