SAE J30 R10 DIN73379 NBR Rubber Braided Diesel Oil Heat Resistant Fuel Hose

Supplier: Hengshui Yatai Especial Rubber Products Co., Ltd.
Region: Hebei, China
Contact: Ms Amy Cui
Price: $1.13 / >=500 meters
Min. Order: 500 meters

Click here to contact

Product details

Year:	2017-2019;	Single gross weight:	0.34 KG;
Working temperature:	-40℃ to +121℃;	Engine:	6.0;
Single package size:	55X55X10.8 cm;	Year:	2017-2019;
Year:	2004-2016;	Engine:	5.2 FSI RWS;
Selling Units:	Single item;	Size:	3/8";
Brand Name:	YATAI;	Engine:	3.0 S Q4;
Model:	MC 12, Quattroporte VI;	Engine:	50 TDI quattro;
Package Type:	1.The default is the wear-resistant woven strip packaging 2.If you need other packaging like wooden box and pallet,please contact us. 3.The volume is for 1 roll and the weight is for 1 m.;	Certification:	ISO9001 CCS;
Year:	2017-2019;	Package Preview:	https://sc01.alicdn.com/kf/H925a7283dd9044a3a154a2e068a4f35by.jpg_640x640.jpg;
Working Pressure:	3.4bar;	Car Fitment:	Audi,Maserati;
Tube:	Fuel and oil resistant synthetic rubber compound;	Product name:	SAE J30 NBR Rubber Braided Diesel Oil Heat Resistant Fuel Hose;
Reinforcement:	ONE TEXTILE BRAID;	Model:	A8, R8;
Warranty:	1year;	Cover:	ENVIRONMENT RESISTANT SYNTHETIC RUBBER;
Color:	Red and as you like;	Car Model:	car & truck;

SAE J30 R10 DIN73379 NBR Rubber Braided Diesel Oil Heat Resistant Fuel Hose

APPLICATIONS

Low pressure lines, return lines, drain lines

Mineral oils, vegetable and rape seed oils, glycol and polyglycol based oils, synthetic ester based oils, oils in aqueous emulsion, water

HOSE MARKING:YATAI HYDRAULIC HOSE SAE 100 R6 1/4″ EN854 1TE DN6 W.P.28BAR 410PSI

YATAI PART.REF.	HOSE SIZE I.D			R.O.D	O.D	MAX W.P		MIN B.P		MIN B.R	W.T
YATAI PART.REF.	DN	dash	inch	mm	mm	bar	psi	bar	psi	mm	Kg/m
TB R6 5	5	-3	3/16"	-	11.1	34	493	110	1972	51	0.10
TB R6 6	6	-4	1/4"	-	12.7	28	406	110	1624	64	0.13
TB R6 8	8	-5	5/16"	-	14.3	28	406	110	1624	76	0.15
TB R6 10	10	-6	3/8"	-	15.9	28	406	110	1624	76	0.18
TB R6 12	12	-8	1/2"	-	19.8	28	406	112	1624	102	0.26
TB R6 16	16	-10	5/8"	-	23.0	24	348	100	1392	125	0.31
TB R6 19	19	-12	3/4"	-	26.6	17	247	85	988	140	0.47
TB R6 25	25	-16	1"	-	35.2	17	247	85	988	150	0.71

CONTINUOUS SERVICE TEMPERATURE RANGE: -40°F / +250°F; -40°C / +121°C
INSERT: SHF TYPE
TUBE: OIL RESISTANT SYNTHETIC RUBBER
REINFORCEMENT: ONE HIGH RESISTANCE TEXTILE BRAID
COVER: ENVIRONMENT RESISTANT SYNTHETIC RUBBER
APPLICABLE SPECS: SAE 100 R6 - EN 854 R6/1TE - ISO 4079-1 R6/1TE
