High Pressure Gray Cloth Surface One Fiber Braid 5/16 Inch Sae 100 R6 Oil Water Air Rubber Hose

Supplier: Hengshui Yatai Especial Rubber Products Co., Ltd.
Region: Hebei, China
Contact: Ms Amy Cui
Price: $0.76 /meter
Min. Order: 1 meter

Click here to contact

Product details

Model Number:	5/16";	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Tube:	Oil resistant synthetic rubber;	Reinforcement:	One high resistance textile braids;
Raw Material:	Imported in South Korea KUMHO;	Standard:	EN 854 1TE/SAE 100 R6;
Place of Origin:	China;	Port:	Tianjin;
Color:	Customized;	Length:	50m/roll;
Supply Ability:	888888 Meter/Meters per Month;	Working pressure:	28bar;
Surface:	Wrap or smooth;	Packaging Detail:	1.The default is the wear-resistant woven strip packaging 2.If you need other packaging like wooden box and pallet,please contact us. 3.The volume is for 1 roll and the weight is for 1 m.;
Cover:	Environment resistant synthetic rubber;	Brand Name:	YATAI;
Package Preview:	https://sc02.alicdn.com/kf/Hae843dfdc18b485b8eaefd35ab4f6b26G.jpg_640x640.jpg;	Working temperature:	-40°C / +121°C;

High Pressure Gray Cloth Surface One Fiber Braid 5/16 Inch Sae 100 R6 Oil Water Air Rubber Hose

Product Description

APPLICATIONS

Low pressure lines, return lines, drain lines

Mineral oils, vegetable and rape seed oils, glycol and polyglycol based oils, synthetic ester based oils, oils in aqueous emulsion, water

HOSE MARKING:YATAI HYDRAULIC HOSE SAE 100 R6 1/4″ EN854 1TE DN6 W.P.28BAR 410PSI

YATAI PART.REF.	HOSE SIZE I.D			R.O.D	O.D	MAX W.P		MIN B.P		MIN B.R	W.T
YATAI PART.REF.	DN	dash	inch	mm	mm	bar	psi	bar	psi	mm	Kg/m
TB R6 5	5	-3	3/16"	-	11.1	34	493	110	1972	51	0.10
TB R6 6	6	-4	1/4"	-	12.7	28	406	110	1624	64	0.13
TB R6 8	8	-5	5/16"	-	14.3	28	406	110	1624	76	0.15
TB R6 10	10	-6	3/8"	-	15.9	28	406	110	1624	76	0.18
TB R6 12	12	-8	1/2"	-	19.8	28	406	112	1624	102	0.26
TB R6 16	16	-10	5/8"	-	23.0	24	348	100	1392	125	0.31
TB R6 19	19	-12	3/4"	-	26.6	17	247	85	988	140	0.47
TB R6 25	25	-16	1"	-	35.2	17	247	85	988	150	0.71

CONTINUOUS SERVICE TEMPERATURE RANGE: -40°F / +250°F; -40°C / +121°C
INSERT: SHF TYPE
TUBE: OIL RESISTANT SYNTHETIC RUBBER
REINFORCEMENT: ONE HIGH RESISTANCE TEXTILE BRAID
COVER: ENVIRONMENT RESISTANT SYNTHETIC RUBBER
APPLICABLE SPECS: SAE 100 R6 - EN 854 R6/1TE - ISO 4079-1 R6/1TE

More Product

Packaging & Shipping

Certifications

FAQ

FAQ:

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white wearable woven bags. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q4. How about your delivery time?
A: Generally, it will take 20 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
