Shape: | roll; | Type: | PP; |
Place of Origin: | Zhejiang China; | Packaging Detail: | box and then put into cartoon; |
Port: | Shanghai or Ningbo; | Supply Ability: | 3000 Roll/Rolls per Day; |
Application4: | disc membrane; | Brand Name: | Tianshan filter; |
Diameter: | 142mm; | Application3: | lab testing; |
Application2: | industrial filtration equipment; | Delivery Detail: | 5-10days; |
certificate: | SGS; | Payment Terms: | T/T,Western Union; |
Model Number: | Disc membrane; | mode: | roll membrane; |
color: | white; | Application1: | Gas filter; |
welcome to>>Hangzhou Tianshan Precision Filter Material Co., Ltd.
Mixed cellulose membrane
| Features
| Hydrophilic, no prewetting |
High flow rates and thermal stability | ||
Low protein adsorption | ||
Low protein adsorption | ||
Application | Widely used in analytical and laboratory filtration | |
Polytetrafluoroethylene (PTFE) Membrane
| Features
| Permanently hydrophobic |
Excellent chemical compatiblity | ||
High temperature resistant | ||
Broad pHPore size: 0.10um - 3.00um-range of pH 2-14 | ||
Application
| Air/gas sterile filtration | |
Aggressive chemicals, reagents and solvents bacterial removing |
Technical Specification
Membrane Name | Nylon | PES | |||||
Pore Size (um) | 0.20 | 0.45 | 0.65 | 0.20 | 0.45 | 0.65 | |
Buble Point (Mpa) | 0.30 | 0.20 | 0.15 | 0.33 | 0.22 | 0.18 | |
pH Value | 6 - 13 | 2 - 14 | |||||
Water Flow Rate mL/cm2/min (ΔP=1.0bar) | Water | Water | |||||
23℃ | 23℃ | ||||||
>7 | >20 | >50 | >20 | >40 | >75 |
PVDF | CN-CA | PTFE | ||||||
0.20 | 0.45 | 0.80 | 0.20 | 0.45 | 0.65 | 0.10 | 0.20 | 0.45 |
0.09 | 0.06 | 0.04 | 0.30 | 0.20 | 0.15 | 0.15 | 0.10 | 0.07 |
1 - 14 | 4 - 8 | 1 - 14 | ||||||
Ethanol | Water | Air Flow Rate | ||||||
23℃ | 23℃ | m3/m2„/h | ||||||
>7 | >18 | >45 | >10 | >25 | >55 | >2 | >4 | >6 |
Sterilization | by autoclaving (121 ℃ at 1 bar) or with ethylene oxide. |
ORDER INFORMATION
PRODUCT | Membrane | Pore Size | Diameter | |||||||
MF | PN - Nylon | 010 - 0.10 um | 013 - 13mm | |||||||
PS - PES | 020 - 0.20 um | 025 - 25mm | ||||||||
PV - PVDF | 045 - 0.45 um | 047 - 47mm | ||||||||
PF - PTFE | 065 - 0.65 um | 090 - 90mm | ||||||||
CNCA - CN-CA | 080 - 0.80 um | 142 - 142mm | ||||||||
100 - 1.00 um | 293 - 293mm |
Package | |||||
25G - | 25 pcs in a case with paper separated | ||||
50N - | 50 pcs in a case without paper separated | ||||
How to order ?-Example | |||||
Membrane: Nylon, Pore Size: 0.20 um, Diameter: 47mm | |||||
Package: 25pcs in a case with paper separated | |||||
Selection code is: MFPN02004725G |
pleated filter cartridge | Metal filter cartridge | Other filter cartridge | Filter Housing |
PN filter cartridge series | Titanium alloy sintered filter | Small Filter cartridge | Gas Filter housings |
PES filter cartridge series | pleated stainless steel filter | ZP filter/ single piece filter | Liquid Filter housings |
PTFE filter cartridge series | stainless steel sintered filter | High flow cartridge | Bag Filter housings |
PVDF filter cartridge series | String Wound filter | Titanium filter housing | |
PP filter cartridge series | Melt-blown Filter | filter flask | |
GF filter cartridge series | Activated carbon block filter | Plate filter | |
mesh filter cartridge | |||
Filter Membranes | Filter cloth | Capsule Filter | |
Nylon Membrane | Polyester fiber filter cloth | ||
PES Membrane | Polyamide fiber filter cloth | ||
PVDF Membrane | Polypropylene fiber filter cloth | ||
CN-CA membrane | Filter bag | ||
1,24-hour Response
We responds any request from our clients within 24 hours, saving your time and labor.
2,Supporting System
The system consists of claims systems, technical support system, inquiry system and ordering following system. The system will provide after-sales service in full range.
3,Free Training
We provide free training to all of our clients and distributors. The training will give you ample knowledge of our product, and make it easy for your work.
4,Free Storage Area
We are providing free storage area to our client,to achieve mix loading purposes.
1 How can we get the quotation of flter cartridges
Kindly please let us know the specifications,such as the material,length,micron,adapter,apply in which industry.....
2What's the minimal quantity requested?
We do not the requirement on teh minimal demand.Thank you.
3How long about your delivery ?
The order is always arranged in 10 working days as soon as receiving the deposit or payment
