Leadshine driver DM2282 digital stepper driver 2.2~8.2A work 80~220VAC

Supplier: Sichuan Hongjun Science And Technology Co., Ltd.
Region: Sichuan, China
Contact: Mr Jack Yan
Price: $105.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Type:	Leadshine driver DM2282 digital stepper driver;	Place of Origin:	Guangdong China;
Package Type:	Leadshine driver DM2282 digital stepper driver;	Motor Type:	Stepper Motor;
Brand Name:	Leadshine;	Single gross weight:	2 KG;
Power Supply:	DC;	Model Number:	DM2282;
Logic Signal Current:	36-80VAC;	Supply Voltage:	1-480V;
Selling Units:	Single item;	Single package size:	15X15X10 cm;
Output Current:	2.2~8.2A;

Leadshine driver DM2282 digital stepper driver

Features

The DM2282 is a high voltage, versatility fully digital stepping drive based on a DSP with advanced control algorithm. It brings a unique level of system smoothness, providing optimum torque and nulls mid-range instability. Motor auto-test and parameter auto-configuration technology offers optimum responses with different motors and easy-to-use. The driven motors can run with much smaller noise, lower heating, smoother movement than most of the drivers on the markets. Its unique features make the DM1182 an ideal solution for applications that require low-speed smoothness.

Extra-low motor noise offers excellent quietness

Anti-Resonance, provides optimum torque and nulls mid-range instability

Self-test and Auto-configuration technology, offers optimum responses with different motors

Microstep resolutions programmable, from full-step to 102,400 steps/rev

Supply voltage up to 150 VAC

Output current programmable, from 0.5A to 8.2A

Pulse input frequency up to 200 KHz

Automatic idle-current reduction

Supports PUL/DIR and CW/CCW modes

Specfications

Model	Phase	Current(A)	Voltage(V)	Microstep resolution	Adaptive motor	Weight(kg)	Dimensions(mm)
DM422	2	0.5-2.2	18-36 DC	1-256	39 42	0.15	865520
DM442	2	1.4-4.2	18-36 DC	1-256	42 57	0.2	1166926.5
DM542	2	1.0-4.2	18-48 DC	1-256	57 86	0.23	11875.533
DM556	2	2.1-5.6	18-48 DC	1-256	57 86	0.28	11875.533
DM856	2	2.1-5.6	18-70 DC	1-256	57 86	0.28	11875.533
DM870	2	2.1-7.0	18-70 DC	1-256	57 86	0.28	11875.533
DM860	2	2.4-7.2	18-80 DC	1-256	57 86	0.38	1519748
DM1182	2	2.2-8.2	90-130 AC	1-256	86 110	1.3	20014583
DM2282	2	2.2-8.2	180-240 AC	1-256	86 110 130	1.7	20014583
3DM580	3	2.5-8.0	18-48 DC	1-256	57 86	0.27	11875.534
3DM2283	3	2.9-11.7	180-240 AC	1-256	86 110 130	1.7	20014583

Application

For a variety of small and medium sized automation equipment and instruments, such as: laser processing equipment, engraving equipment, medical equipment, measuring equipment, electronic processing equipment, textile and garment equipment. User expectations low vibration, low noise devices used in, the better
