High power portable off grid home solar energy storage power

Supplier: Shenzhen Jinsdon Lighting Technology Co., Ltd.
Region: Guangdong, China
Contact: Ms Rosalind tang
Price: $140.00 / >=10 pieces
Min. Order: 10 pieces

Click here to contact

Product details

Work Time (h):	24hours;	Controller Type:	solar charge controller;
Size:	275261153mm;	Load:	light,refrigerator,air conditioner;
Single package size:	30X20X25 cm;	Product name:	solar energy systems for home;
Type:	Off-grid System;	Solar Panel Type:	Monocrystalline Silicon;
Use life:	25years;	Model Number:	ups-a8;
Output Voltage (V):	12;	Package Type:	carton;
Specification:	Normal;	Load Power (W):	customizable;
Weight:	About 5.5kg;	Feature:	PAYGO,FM Radio,MP3 Player etc.;
Brand Name:	BYD;	Warranty:	10 Years;
LiFePo4 battery:	12V /9Ah;	Battery Type:	Lithium;
Mobile charge:	5W*11Hours;	Place of Origin:	Guangdong China (Mainland);
Delivery Detail:	0 days after payment;	Selling Units:	Single item;
Application:	Commercial;	Single gross weight:	7 KG;

High power portable off grid home solar energy storage power systems home

Product Description

Technical parameters

Title	Model	UPS-W25	UPS-W35	UPS-W50
Main Engine	12V DC Output	12V 4A	12V 4A	12V 4A
	USB 5V Output	5V 2A	5V 2A	5V 2A
	Battery Capacity	128WH	192WH	275WH
	Weight(KG)	5.6	5.8	6
	Dimension(MM)	270180210	270180210	270180210
Solar Panel	Power	25	35	50
	Voltage	12	12	12
	Weight(KG)	2.2	2.6	4.5
	Dimension(MM)	525340170	505440250	630505250
Environment Requirements	Charging Temperature	0~55℃	0-55℃	0-55℃
	Discharging Temperature	-20~60℃	-20~60℃	-20~60℃
	Storage Temperature	0~45℃	0~45℃	0~45℃

Other information

Package Content	main engine1 (swipe card type)with IC card 2, multi-USB cable1, 5W led bulb(with cable)5, solar panel with cable1, product manual 1, warranty card *1
Solar Panel Cable	2*2.5mm?, 8m
Battery Type	Lithium iron phosphate battery
MP3 Player	Optional
Radio Function	Optional
Insert memory card to play	Optional
5V USB Fan	Optional
Warranty	System: 2 years; Accessories:1 yeas

This leasing type integrated photovoltaic energy storage machine is manufactured by Jinsdon Lighting. This system can provide a low-cost and long-term benefits solar power supply service to operator's customer group. This product is equipped with high-efficiency solar panel, LiFePO4 battery, 12V DC port, and 5V USB Mobile phone charging interface, having two kinds of password payment methods: by card and by key, convenient use, low operating cost.

Feature

1. Customized single high-capacity automotive battery, long cycle life, service life can last up to 10 years.
2. Small portable design, suitable for indoor and outdoor different place use.
3. The user can use it by input password or insert IC card, simple and convenient operation.
4. Operators get the password through website/client software. Operators put the IC card on the reader, the website/client software will read the number and generate the password then write it into the card automatically. The process does not exceed 2 seconds, very easy
and convenient.
5. Adopt MPPT charging mode, charging efficiency up to 98%
6. With mature technology monocrystalline silicon solar panel, high photoelectric conversion efficiency, sturdy and durable.

Lithium iron phosphate battery

The high capacity and high efficiency lithium iron phosphate batteries have a tenfold higher cycle life than traditional lead-acid batteries and digital lithium batteries.

Monocrystalline silicon solar panel

Using monocrystalline silicon solar panels, reliable technology, its photoelectric conversion efficiency is up to 18%, and service life can reach 20-25 years, support customization

Wide application

Integrated portable design, can be used not only indoors, but also outdoor. Suitable for indoor, grassland pasturing areas, mountains forests, vast fields, Island, trawler, remote frontiers, desert areas, markets or stalls, orchards, apiaries, snowfield and other places to use electricity

Note:

1. Do not let this product be exposed to the sun or rain, except for the solar panels.

2. The voltage of the two output ports is different. If you are not sure, please do not use the 12V DC port to charge the 5V input devices such as mobile phones.
