New Woodworking Machinery Semi-automatic Finger Joint Line

Supplier: Qingdao High-Class Service Import & Export Co., Ltd.
Region: Shandong, China
Contact: Ms Cindy Yu
Price: $41000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Keyword:	Finger joint line;	Place of Origin:	Shandong China;
Website:	www.hicasmach.com;	Weight (KG):	5800 KG;
Package Preview:	;	Packaging Detail:	plywood crate;
Warranty of core components:	1 YEAR;	Name:	Finger Joint Line;
Payment Terms:	L/C,T/T;	Applicable Industries:	Manufacturing Plant;
Voltage:	220V/380V;	Marketing Type:	Ordinary Product;
Dimension(LWH):	13.5*5.5m;	Key Selling Points:	High productivity;
Local Service Location:	none;	Machinery Test Report:	Provided;
Power:	45kw;	Certification:	ISO9000;
Warranty:	One year,1 Year;	Air Pressure:	6-8bar,0.6-0.8Mpa;
After Warranty Service:	Video technical support,Field maintenance and repair service;	Color:	As per your request;
Model:	HC1560A*600II;	Place Of Origin:	Shangdong;
Video outgoing-inspection:	Provided;	Showroom Location:	none;
Brand Name:	HICAS,HICAS;	Condition:	New;
Core Components:	/;

New Woodworking Machinery Semi-automatic Finger Joint Line

Product Description

Specifications	Working length	150-850mm
	Working thickness	20-80mm
	Working width	30-150mm
	Pressing thickness	15-80mm
	Pressing width	30-150mm
	Shaper spindle diameter	70mm
	Shaper spindle speed	6000rpm
	Main saw blade spindle speed	2840rpm
	Shaper cutter out side diameter	160mm
	Main saw blade size	255mm
	Max. thrust force	7800kg
	Max. Assembly length	2500mm (HS-2500)
	Max. Assembly length	6000mm (HS-6000)
Motor power	1st Shaper spindle power	16.12kw
	2nd Shaper spindle power	16.87kw
	Conveyor power	0.375kw*3pc
	Assembly machine power	6.7kw
	Total motor power	40.8kw
	Voltage	380v 50hz 3phase
Remark	Working air pressure	0.5-0.8mpa
	Volume of dust collector	9000m³/h
	Machine working dimension	9000*3000mm (HS-2500)
	Length* width	14000*3000mm (HS-6000)

Detailed Images

Related Products

Welcome to click the following products, or send your detailed requirement to us, we will send you Best Price and Full Details.

Why Choose Us

1.15 years experience in Chinese woodworking machinery market.
2.8 years exportation experience, have customers in more than 40 countries.
3.Our engineer with +20 years experience, familiar with woodworking machinery production, installation, operation, maintenance.
4.Through years of deep cooperation, we meet hundreds factories, some with very good technology and service we cooperate till now, some with bad quality and service and always delay for delivery we don't cooperate any more, now we have good relationship with top manufacturers in different cities, with strong technical advantages and competitive price, now we have +30 stable suppliers.
5. Nowadays international business develop so fast, there are too many companies on the internet, all looks good and professional, but with our rich experience we know who is really trustful.
6.To service our customer, we have a team not only a sales person, we have purchase department, engineer department, operation department, and aftersales service team (consist with our factory engineers).

7.Customer Feedback

8.We are Gold Plus & Verified supplier in Alibaba.

9. Our company and products have been verified onsite by SGS Group

10. Our mission and target
Let Chinese woodworking machinery serve the whole world
Create maximum value for customer
Try to be the biggest woodworking machinery exporter in China

We are looking for Good customers like you! and Distributor or Agents Wanted!!!
