New Processing Variable Speed Mini metal Lathe 8x16 Inch mini Lathe CNC Lathe Machine price

Supplier: Shanghai Sihao Machinery Equipment Co., Ltd.
Region: Shanghai, China
Contact: Mr Marketing VEVOR
Price: $599.00 /set
Min. Order: 1 set

Click here to contact

Product details

Spindle Motor Power(kW):	0.75;	Tool Post Stations:	4;
Max. Spindle Speed (r.p.m):	2800 r.p.m;	Positioning Accuracy (mm):	0.5 mm;
Max. Length of Workpiece (mm):	400 mm;	Key Selling Points:	Automatic;
Travel (Z Axis)(mm):	100;	Certification:	CE Certificate;
Travel (X Axis)(mm):	400;	Type:	HORIZONTAL;
Spindle Bore(mm):	21 m'm;	Selling Units:	Single item;
Showroom Location:	none;	Model Number:	210ZXJCC000000001V2;
Condition:	New;	Number of Axes:	4;
Place of Origin:	Shanghai China;	Tailstock:	Taper MT#2;
Applicable Industries:	Mini Metal Lathe;	Structure:	Flat Bed Lathe;
Distance Between Centers:	15-3/4inch (400 mm);	Voltage:	220V;
After Warranty Service:	Online support;	Packaging Detail:	one set in a carton box;
Max. Swing Diameter:	210mm;	Machining Capacity:	Light Duty;
After-sales Service Provided:	Online support;	Weight (KG):	77;
Power(W):	750w;	Swing Over Bed:	8-1/4inch (210 mm);
Spindle Speed Ranges:	Low 50-1250, high 100-2500 RPM;	Width of bed (mm):	100;
Brand Name:	sihao;	Inch Threads:	8-44 TPI;
Metric Threads:	0.5-3.0 mm;	Warranty:	2 years;
Single package size:	91X48X44 cm;	Single gross weight:	77.0 KG;
No. of Spindles:	/;	Dimension(LWH):	844738cm;
Local Service Location:	none;	Max. Swing Diameter (mm):	210 mm;
Footprint:	31-1/2 x 10-1/2 inch;	Cross Slide:	4-5/8inch (117 mm);

Product Description

New Processing Variable Speed Mini metal Lathe 8x16 Inch mini Lathe CNC Lathe Machine price

This precision 8" x 16" Variable-Speed Lathe is designed to perform various types of metal, jade and wood turning. It is perfect for a sturdy workbench or as a stand-alone unit when mounted on a suitable stand. It can be used in areas such as mini precision parts processing, sample processing and modeling works. It is both perfect for hobbyists and modelers who is looking to add finite detail to their construction project. It features variable-speed spindle with high and low speed ranges and convenient quick-lock tailstock.

Application

Suitable for turnings of metal, wood, jade, etc.
Ideal for use in labs, workshops, engineering and education.
Can be turned within foreign aid, turning thread, turning taper and so on.

Main Features

Telescopic sets with scale, you can intuitively see the length of the telescopic handle scale, precise scaling can be digitally standardized or adjusted by lateral movement.
Spindle speed can be adjusted from 50 to 2500 RPM (50-1250 low, 100-2500 high).
Equipped with all-metal gears, this machine is wear-resistant, durable, more accurate rotation and professional.
Multi-function automatic tool.
Accurate operation and professional performance.

Specification

Swing Over Bed:	8-1/4" (210 mm)
Cross Slide:	4-5/8 (117 mm) Distance Between Centers:
Motor Power:	750W
Distance Between Centers:	15-3/4" (400 mm)
Spindle Speed Ranges:	Low 50-1250, high 100-2500 RPM
Travel:	compound rest 2-1/8 (54 mm), cross slide 3 (76 mm)
Tailstock:	Taper MT#2
Tail Sleeve:	φ1" (25 mm)
Hole Thru Spindle:	φ0.83" (21 mm),taper MT#3/MT#5
Feed speeds:	(3) 0.0037–0.0071/rev
Inch Threads:	8-44 TPI
Metric Threads:	0.5-3.0 mm
Footprint:	31-1/2 x 10-1/2
Spindle Accuracy:	0.0004-0.0012" (0.01-0.03 mm)
Main Engine Gross Weight:	128 lbs (58 kg)
Main Engine Package Dimensions (L* W* H):	36* 19* 17" (91* 48* 44 cm)
Standard Equipment:	4 3-Jaw and 4-jaw chucks Steady rest & follow rest 4-Way turret tool post (3/8 max tool size) MT#2 & MT#3 dead centers

Packing & Delivery

Packaging
Size	91(L) * 48 (W) * 44 (D)
Weight	76kg
Packaging Details	1 X 8" x 16" Variable-Speed Lathe 1 X Tool Storage Box 1 X 4" 3-Jaw Chuck 1 X 4" 4-Jaw chuck 1 X Oil Can 1 X Set of Accessories 1 X User Manual
