Supply voltage: | DC12V; | Place of Origin: | Guangdong China; |
Certificate: | CE ROHS; | Power consumption: | ≤ 12 W; |
Function: | Human Face Recognition ,Access Control; | Warranty: | 1 Year; |
Brand Name: | ODM/OEM; | Package Preview: | ; |
Display: | 8 Inch; | G.W(kg): | 1.95kg; |
Supply Ability: | 2000 Piece/Pieces per Week; | Packaging Detail: | 1 pcs in a box,also according to customers requirement; |
Model Number: | FK02GYW; | Product Size (L*W*T): | 219 * 111 * 21.5mm; |
Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; | Port: | Shenzhen; |
Packing size (L*W*H): | 406*185*158mm; | Application: | Schools Office Stations Supermarket; |
Product Specifications:
Model: | FK02GYW |
System | |
Main processor | MX3520 |
operating system | Embedded LINUX |
RAM | DDR3 512MB |
ROM | EMMC 8GB |
Display | |
size | 7 inch IPS HD screen |
Resolution | 736*1280 |
camera | |
Sensor | 1/5 GC2145 |
Resolution | NIR 600*800 15fps |
Lens | 2.4mm |
Face library capacity
|
Supports up to 30,000 sheets |
Recognize face angle | (Daytime) vertical viewing angle 58-60, horizontal viewing angle 35; (living body) vertical viewing angle 48-50, horizontal viewing angle 36 |
Fault tolerance | Ordinary glasses and short sea surface retention time have no effect on recognition |
expression | Under normal circumstances, slight expressions do not affect recognition |
reaction speed | About 200ms |
Facial exposure | stand by |
Local storage | Support 25,000 records |
Recognition area | Full screen recognition |
Upload method | TCP, HTTP, MQTT |
Network features
|
|
Network protocol
|
IPv4, TCP / IP, HTTP |
Interface Protocol
|
no |
Safe mode
|
Authentication username and password |
Alarm linkage mode
|
Voice broadcast, abnormal upload |
System Upgrade
|
Support remote upgrade |
Other
|
/ |
Hardware accessories
|
|
Auxiliary light
|
fill light, white light fill light
|
Identification module
|
no |
speaker
|
Support voice broadcast for successful recognition results |
Network module
|
no |
Hardware interface
|
|
Network Interface
|
RJ45 10M / 100M Network Adaptation |
Alarm input
|
no |
Alarm Output
|
no |
RS485
|
stand by |
TF card slot
|
no |
HDMI
|
no |
Wiegand interface
|
Support Wiegand 26, 34, 66 protocols |
Hard reply button
|
stand by |
Tamper switch | no |
Conventional
|
|
shell | Metal body and bracket, plastic panel, IP66 |
Operating temperature | -20 ° C ~ 60 ° C |
Working humidity | 10% -90% non-condensing |
Storage temperature | -40 ° C ~ 70 ° C |
Storage humidity | 5% -95% non-condensing |
Protection class | / |
Supply voltage | DC12V |
Power consumption | ≤ 12 W |
Size (mm) | 219 (W) * 111 (H) * 21.5 (T) |
Bracket size (mm) | φ25 * 189 |
Installation method | Desktop installation / floor support installation |
