1800w dcdc converter 560v to single 14v Isolated power supply

Supplier: Shijiazhuang Dilong Technology Co., Ltd.
Region: Hebei, China
Contact: Mr Walker Xing
Price: $300.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

size:	175.310750mm;	Type of cooling:	Liquid-cooled or air-cooled;
Model Number:	DE1K8S14-560S14RC;	Brand Name:	DILONG;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Port:	Tianjin;
Operating temperature:	-40℃~+85℃;	Efficiency:	90%;
Constant voltage output range:	275~750Vdc;	Weight:	≤1.5kg;
Supply Ability:	5000 Piece/Pieces per Month 1800w dcdc converter 560v to single 14v Isolated power supply;	Place of Origin:	Hebei China;
Product name:	1800w dcdc converter 560v to single 14v Isolated power supply;	Packaging Detail:	Export standard packing 1800w dcdc converter 560v to single 14v Isolated power supply;
Input current range:	<7A@DC560V;	Input voltage:	560Vdc;

1800w dcdc converter 560v to single 14v Isolated power supply

more products

Product Description

^{Place of Origin: Hebei, China (Mainland)}

^{Brand name: Dilong}

^{Model Number: DE1K8S14-560S14RC}

Specification

DE1K8S14-560S14RCis a highly integrated and highly integrated company specially designed for electric vehicles.

Intelligentized digital DC/DC converter that can be integrated with motor controller.self-actualization

The constant current constant current automatic conversion is suitable for the application design of pure electric vehicle energy conversion.

Model Specification/unit			DE1K8S14-560S14RC
Mains Input	Rated input voltage	V	560Vdc
	Voltage Range	Vdc	200-750
	Efficiency	%	≥95 (Not including auxiliary power supply)
	Power Factor		≥0.99@220Vac,rated power
	Current	A	8.2A @Vin=270V(peak power)
Mains output	Rated output voltage	Vdc	14Vdc(adjustable between 12V-15.6V)
	Max current	A	128A
	Constant power output	W	1800
	Constant voltage output range	Vdc	100~200
	Output voltage accuracy	V	≤±1%Vo input 175Vac-265Vac,output 10%-100% load
	Line regulation	%	≤±1Vo input 175Vac-265Vac,output 100% load
	Load regulation	%	≤±1Vo input 220Vac,output 10%-100% load
	Ripple and noise	mV	≤±3%Vo 20M oscilloscope,Twisted-pair cable test.
Property	Input over-voltage protection	Vac	>275 CAN directive warning protection
	Input under-voltage protection	Vac	<85 CAN directive warning protection
	Output Over-current protection	A	≥110%Io CAN directive warning protection
	Output under-voltage protection	Vdc	< 90 CAN directive warning protection
	Output over-voltage protection	Vdc	>205 CAN directive warning protection
	Over-temperature protection	℃	85±5 CAN directive warning protection
	Output short circuit protection		Yes (CPU Intelligent monitoring )
	Reverse polarity protection		yes (CPU Intelligent monitoring )
	Dynamic response	us	≤200
	CAN communication		Communication interrupt, timeout of 20 seconds intelligent shutdown, communication normal recovery.
Work environment	Operating temperature		-40℃~+70℃(Intelligent derating shell temperature above 70 ℃)
	Storage temperature		-45℃~+95℃
	Operating humidity	%RH	20-90(No condensation)
	Storage humidity	%RH	10-95(No condensation)
	Vibration		QC/T413-2002(Other parts required)
	Type of cooling		Liquid-cooled or air-cooled
Safeguard	Isolation Voltage		shell←input→output:2.8KVdc; Main Output→shell:2.8KVdc; Auxiliary Output→shell:700Vdc
Safeguard	Insulation resistance	MΩ	input—output—shell>10 (25℃,70%RH)
Structure	weight	Kg	≤1.5Kg
Structure	Dimensions	mm	175.310750mm

Factory

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

7-30 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
