6000W OBC and 1500W DC-DC 2 in 1 integrated electric vehicle professional and adjustable battery charger

Click here to contact

Product details

Brand Name:	DILONG;	Output voltage to BMS:	12Vdc 100W;
Packaging Detail:	Export standard packing 6000W OBC and 1500W DC-DC 2 in 1 integrated electric vehicle professional and adjustable battery charger;	Efficiency:	95%;
Type of cooling:	Liquid cooling;	CAN communication:	yes;
Port:	Tianjin;	Output to high voltage battery:	360Vdc;
Input voltage:	220Vac;	Output to low voltage battery:	14VDC;
Supply Ability:	3000 Set/Sets per Month 3000W OBC and DC-DC 2 in 1 electric vehicle battery professional;	Weight:	12kg;
Place of Origin:	Hebei China;	Model Number:	DA8KM22A-362C-14C;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	IP Grade:	IP67;
Power:	8KW;

Product Description

Place of Origin: Hebei, China (Mainland)

Brand name: Dilong

Product name: DA8KM22A-362C-14C

Specification

Onboard battery charger and dc-dc converter integrated charger for electric vehicles!

OBC part main parameters:

Mains Input	Rated Voltage	Vac	220
	Voltage Range	Vac	85~264 (85~175 the power dropped to 1200W)
	FREQ Range	HZ	47~63
	Efficiency(MAX)	%	≥95
	Power Factor		≥0.99@220Vac,rated power
	Current	A	≤16A@220Vac
Mains output	Rated output voltage	Vdc	70
	Constant voltage output range	Vdc	250~420 (According to customer battery decision)
	Maximum current	A	25
	Maximum power	W	6600
	Output voltage accuracy	V	≤±1%Vo input 176Vac-264Vac,output 10%-100% load
	Line regulation	%	≤±0.2%Vo input 176Vac-264Vac,output 100% load
	Load regulation	%	≤±0.5%Vo input 220Vac,output 10%-100% load
	Ripple and noise	mV	≤±3%Vo 20M oscilloscope,Twisted-pair cable test.
Auxiliary supply	Rated output voltage	Vdc	14
Auxiliary supply	Rated output power	W	100

DC-DC part main parameters:

Project	Specifications	Note
Rated input voltage/current	DC:360V/4.6A
Input voltage range	DC:220V~420V
Output rating	DC:14V	(The shell is DC14V output negative)
Output current	107A(rated), 128A(peak)
Output power	1500W(rated), 1800W(max/6mins)
