Packaging Detail: | Less than Container Load ( LCL) Service to US ,Get shipping quote. Hot Sale Support Bluetooth Reflectorless Total Station packing in carton box; | Model: | TS3-1; |
Output Interface: | Big data storage and bluetooth connection; | Distance measurement: | with prism 5000m; |
Product name: | total station; | Product size: | 160*150*330mm; |
Warranty: | 1 years; | Weight: | 5.8KG; |
Selling Units: | Single item; | Angle accuracy: | 2"; |
Package Preview: | ; | Carton Size: | 0.53*0.33*0.41cm; |
Imaging: | Erect; | Single package size: | 55X45X35 cm; |
Customized support: | OEM,ODM,OBM; | Single gross weight: | 20.0 KG; |
Place of Origin: | Jiangxi China; | Model Number: | TS3-1; |
Brand Name: | Sunway; | Type: | ATS120R; |
Total Station Data
Models and technical parameters | TS3-1 | ||
Telescope | Imaging | Erect | |
Magnification | 30X | ||
Objective aperture | Telescope: 45mm | ||
Field of view | 1 º30” | ||
Minimum of focusing distance | 1.2m | ||
Resolution | 3” | ||
Angle measurement | Angle measurement mode | Absolute angle encoder system | |
Minimum reading | 1”/5”/10” | ||
Accuracy | 2” | ||
Angular unit | DEG/MIL/GON | ||
Display | Double LCD display | ||
Level | Plate level | 30”/2mm | |
Circular level | 8'/2mm | ||
Power type | Laser spot | About2.5mm/1.5m ellipse | |
Distance measurement | With prism | 5000 | |
Reflector(60*60) | 800m | ||
Compensation | Electric | Automatic vertical compensation | |
Range | ±3' | ||
Accuracy | 1' | ||
Output Interface | Big data storage and bluetooth connection | ||
Power | Battery | hydrogen battery/lithium battery | |
Voltage | 7.4V | ||
Weight | 5.8kg | ||
Size | 160*150*330mm |
