Production Capacity: | 10-15m/min; | Roller material: | High Grade 45# Forged Steel; |
Cutting system: | Hydraulic Cutting; | Cutting blade material: | Cr 12 Mov; |
Condition: | New; | Warranty: | 1 Year; |
Key Selling Points: | Long Service Life; | Power: | 5.5KW; |
Brand Name: | DIXIN; | Certification: | ce; |
Work Pressure: | 245-550pa; | Weight: | 4TON; |
Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; | Type: | Steel Frame & Purlin Machine; |
Voltage: | 380V 3PH 50HZ; | Product name: | U Channel Roll Forming Machine; |
Control system: | PLC(imported Brand); | Supply Ability: | 100 Set/Sets per Month U Channel Roll Forming Machine; |
Packaging Detail: | U Channel Roll Forming Machine shipped by nude; | Place of Origin: | Hebei China; |
Raw material: | Galvanized Steel Sheet; | Port: | tianjin; |
Dimension(L*W*H): | 5.5*1.4*1.5M; | Applicable Industries: | Building Material Shops,Construction works ; |
Shaft material: | 45# High Grade Steel; | Drywall roll forming machine: | Profiles Roll Fomring Machine; |
Color: | Customers' Requires; | After-sales Service Provided: | Online support,Free spare parts,Field installation, commissioning and training,Field maintenance and repair service,Video technical support; |
Combined C U Channel Roll Forming Machine Working Process:
No. | Name | Size and mode | number | note |
1 | base frame | 100*100*6 | 1 | |
2 | Control station | 1 | Include switch button | |
3 | Hydraulic station | 4kw | 1 | |
4 | Oil pump | 63*80*80 | 1 | |
5 | Cooling device | 35Hz | 1 | |
6 | Sensor | Npu | 2 | |
7 | Encoder | 600 | 1 | Omron |
8 | tachometric wheel | 2 | ||
9 | Servo motor | 3.9kw | 1 | GSK |
10 | Mold | Mulfan1 | 4 | |
11 | Lead screw | Sfu4020-1230 | 1 | Taiwan |
12 | Guide | HG35-2000 | 2 | |
13 | Slider | HGH35cA | 4 | |
14 | Coupling | 4 |
Usage: In order to keep the product shape and precision, adopts
welded sheet structure, motor reducer drive, gear transmission,
roller surfaces polishing, hard plating , heat treatment and galvanize
treatment . The polished surface and the heat treatment towards
the molds also can keep the molding plate surface smooth and not
easy to be marked when it is being stamped.
Size of main part: About 5.5*1.4*1.5m (L*W*H)
Weight of main part: 4.5Tons
Main power: 5.5kw
Voltage: 380V/50HZ/3Phase
Frame type: Memorial arch frame
Frame thickness: 25mm
Drive mode: By gear
Material of rollers: GCr12MoV
Material of shafts: 45# steel with tempering
Diameter of shafts: φ40mm
Number of rollers: 11 rollers
Material: GI/PPGI
Material thickness: 0.3-0.6 mm
Forming speed: 25 meter/minute
1. One year warranty, whole life technical support.
2. Installation & adjustment : We can take a video for the customer and the customer can also come to our factory, we can train customer how to install and adjust the machine.
3. Oversea service: the buyer should charge of visa, return ticket, food and accommodation overseas and USD100/person/day salary.
