Dimensions: | 540*290*370mm; | Model Number: | CUT-45; |
Certification: | CE ISO; | MAX Cutting thickness: | 16mm; |
Weight (KG): | 24KG; | Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram; |
Cover: | nylon plastic; | Key Selling Points: | Low Maintenance Cost; |
Marketing Type: | New Product 2020; | Function: | Inverter IGBT Cutting Machine; |
Supply Ability: | 5000 Piece/Pieces per Month; | Warranty: | 1 Year; |
Package Preview: | ; | Year: | 2020; |
Rated duty cycle: | 30%; | Motor Type: | Stepper Motor; |
Showroom Location: | None; | Air Flow Rate: | 6.7CFM; |
Plasma ARC START: | Pilot LF; | Machinery Test Report: | Provided; |
After Warranty Service: | Video technical support,Online support,Spare parts; | Core Components: | Motor,Pressure vessel,Engine; |
Applicable Industries: | Building Material Shops,Machinery Repair Shops,Farms,Home Use,Retail; | Packaging Detail: | CUT-45M Carbon Max Duty Metal Steel Training Power Technical Parts Dimensions packed in a honeycomb box; |
output current range: | 20-45A; | Port: | NingBo; |
After-sales Service Provided: | Video technical support,Online support,Free spare parts; | Plasma cutting thickness: | 2-20mm; |
Cutting material: | Metal Stainless Steel Carbon Steel; | Power: | 5.5kw; |
Video outgoing-inspection: | Provided; | Dimension(L*W*H): | 540*290*370mm; |
Voltage: | 230V; | Local Service Location: | None; |
Condition: | New; | Place of Origin: | Zhejiang China; |
Warranty of core components: | 1 Year; | Rated Power: | 5.5KW; |
Brand Name: | Fengbao; |
Product Model: | CUT-45 MONSTER(B) | ||||||
Product Description: | IGBT INVERTER PILOT AIR PLASMA CUTTING MACHINE | ||||||
Rated Input Voltage: | 1phase, 230V +/- 15% | 1phase, 120V/230V +/- 15% | |||||
Rated Input Power: | 5.5Kw | ||||||
Frequency: | 50/60Hz | ||||||
Output Current: | 10-40A | 10-30A | |||||
Rated Duty Cycle: | 40% | ||||||
Plasma ARC Start: | PILOT - LF | ||||||
Air Flow Pressure: | 2.5 Bar (35psi) | ||||||
Air Flow Rate: | 6.7 CFM | ||||||
Cutting Thickness: | Max. 16mm | ||||||
Class of Insulation: | F | ||||||
Protection Level: | IP21 | ||||||
Power Plug: | 20A | ||||||
Size & Weight: | Product Dimension | 570x280x450mm | |||||
Poduct Weight | 14Kg | ||||||
Package Dimension | 620x320x480mm | ||||||
Package Weight | 18Kg | ||||||
Accessories: | 1x S45 CUT TORCH with 3m cable | ||||||
1x 300A Ground Clamp with 2m cable | |||||||
1x CUT Torch kit | |||||||
1x Manual Book | |||||||
