Fiber Laser Sheet Cutting Machine KAFA-GEC Series

Product details

Laser Cutter Equipment Main Configuration:

NameOrigin and Manufacturer name
Special laser cutting head (auto focus)RAYTOOLS
Cutting machine bed (steel plate welding)Self-produced
BeamIntegrated Cast Aluminum
GuideTaiwan HIWIN
ReducerJapanese Ximpo
Gear, rackTaiwan K.H/Germany Herion
Servo motor and driverJapan Panasonic/YASKWA
Control Cabinet Self-Produced
Low-voltage electrical appliancesChint/France Schneider
Origin, limit switchSwiss Carole
CableFlexible Shielded cable
TransformerShenzhen Xinbei Ocean
IPCTaiwan Advantech
CNC system (including control software, height controller)Cyp Cut
Oil RoadElectric oil pump
Gas circuit (proportional valve)NNT
ChillerHan Li


Industrial Fiber Laser Sheet Cutting Machine with more accuracy

Suitable for variety of cutting operations with a maximum working area of 12000mm*2500mm


Active Anti-Collision Function laser heads



  1. Main Technical Parameters of Fiber Laser Cutting Machine

    Device Model

    KAFA GEC-Series

    Laser Cutter Type

    Fiber-optic laser

    CNC laser Cutter Wavelength1064nm
    Rated output power2000W
    Beam quality<0.373mrad
    X axis travel

    3020mm

    Y axis travel1520mm
    Z axis travel100mm
    Effective Cutting Range

    3000*1500m

    Workbench axial positioning accuracy <+0.05mm/m
    Worktable repeat positioning accuracy<+0.02mm/m
    Maximum empty speed60m/min
    Workbench Maximum load 200KG
    Phase3
    Power supply rated voltage

    380

    Frequency 50Hz
    Total power protection levelIP54


    Zero Quivering while cutting thin sheet

Advantages of new Stretching Aluminium Crossbeam


    Tenon-and-mortise Type Plate welding structure bed



      1. Cutting Metal Performance Table:

        MaterialThickness(mm)Speed(m/min)Power(W)Auxiliary Gas
        Stainless Steel1
        2

        3

        4

        5
        6

        8

        1

        2

        3

        4

        5

        6

        8
        35
        10

        6.5

        4

        2.4

        1.6

        0.9

        30

        9

        6

        3.2

        2

        1.2

        0.6
        2000
        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000
        Air
        Air

        Air

        Air

        Air

        Air

        Air

        N2

        N2

        N2

        N2

        N2

        N2

        N2
        Carbon Steel1

        2

        3

        3

        4

        4

        5

        6

        8

        10

        12

        14

        16
        9
        4.2

        3.8

        3

        3.3

        2.8

        2.6

        1.8

        1.3

        1.1

        1

        0.9

        0.8
        2000
        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000
        O2
        O2

        O2

        O2

        O2

        O2

        O2

        O2

        O2

        O2

        O2

        O2

        O2
        Brass1
        2

        3

        4

        5
        25
        7.5

        3.5

        1.8

        0.8
        2000
        2000

        2000

        2000

        2000
        N2
        N2

        N2

        N2

        N2
        Aluminum1
        2

        3

        4

        5

        6

        8

        1

        2

        3

        4

        5

        6
        30

        8

        4

        2.5

        2

        1

        0.6

        30

        9

        3.2

        2

        1.4
        0.8
        2000
        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000

        2000
        N2
        N2

        N2

        N2

        N2

        N2

        N2

        Air

        Air

        Air

        Air

        Air

        Air
        Copper1
        2

        12
        4
        2000
        2000
        O2
        O2
        Galvanized Sheet1
        2

        3
        25
        9

        4.5
        2000
        2000

        2000

        N2


        N2


        N2



        Working Process & Sample
