2022 New Double Layer T-shirt Shopping Bag Making Machine With Four Lines Biodegradable PE Plastic

Supplier: Wenzhou Ruixin Plastic Machinery Trading Co., Ltd.
Region: Zhejiang, China
Contact: Ms Rita Yuan
Price: $4000.00 /set
Min. Order: 1 set

Click here to contact

Product details

application:	Vest bag/Vest bag/Shopping bag	Mechanical test report:	if
Package type:	vest bag	Material:	plastic
Type of machine:	Making Machine	Package preview:
Main selling points:	energy saving	product name:	Making Machine
Dimensions (LWH):	3.2X1.1X1.6M	Marketing Type:	New product
Processing type:	Heat sealing and cold cutting	Maximum speed:	250pcs/min
Supply capacity:	50 sets per month	State of health:	new
port:	Ningbo, Shanghai, Guangdong	line:	four lines
Programmable Controllers:	yes	Computerized:	yes
speed:	400-600 pieces/minute	model:	GBDE-700
Bag length:	400-1000mm	Core components:	motor, bearing
servo motor:	yes	Showroom location:	Saudi Arabia
Warranty:	1 year	Packaging Details:	Film packaging or wooden case
payment terms:	Western Union, T/T	Core component warranty:	1 year
Applicable industries:	manufacturing plant	place of origin; place of origin:	Zhejiang, China
Voltage:	220V	usage:	T-shirt bag making
weight:	1500 kg	brand:	Ruixin
Video shipment inspection:	if	Bag width (maximum):	100-600mm

2022 New Double Layer Four Lines PE Biodegradable Plastic Shopping T-shirt Bag Making Machine:

This shopping vest bag making machine is suitable for producing HDPE and LDPE plastic bags. Stepper motor (servo motor) is used for high-speed discharge, photoelectric tracking and cutting, and one tooth punches out "U"-shaped bags. And it has the characteristics of simple operation, high efficiency and high yield.

Siemens motor

Delta Inverter

touch screen changer

Yaskawa servo motor

Panasonic photocell

Omron electrical parts

Technical Parameters:

Types of	GBDE-700	GBDE-900
Sealing width	150-600mm	180-800mm
Sealing length	300-650mm	300-650mm
Sealing thickness	0.001-0.04mm	0.015-0.04mm
Bag making speed	(5-150)×4pcs/min	(5-150)×4pcs/min
Motor Power	1.5kw	2 kW
machine weight	≈1500kg	≈2000kg
Dimensions (L×W×H)mm	3200×1100×1600mm	5200×1300×1800mm
air compressor	5 kg/cm²	5 kg/cm²

1) It adopts computer control and variable frequency motor speed regulation, which has the advantages of top parking, stability, and accurate positioning.

2) 1 automatic photoelectric feeding system, 1 tracking photocell. Automatic temperature control system, static elimination system, automatic counting system and alarm system.

3) It has an automatic conveying system to convey the sealed and cut bags.

4) Heat sealing and cold cutting. The heat seal has too many sides. One is for making flat bag closures and the other is for making t-shirt bag closures.
