DC-DC DC-AC pure sine wave inverter generator SPWM boost control board EGS002 EG8010 IR2113 RS232 serial port 1602 LCD drive module

feature:

5V single power supply

4-pin group pure sine wave output frequency:


50Hz fixed frequency pure sine wave 60Hz fixed frequency pure sine wave 0-100Hz


Pure sine wave frequency adjustable 0-400Hz Pure sine wave frequency adjustable

Unipolar and bipolar modulation

With Deadband Control, Pin 4 Deadtime:




300nS dead time 500nS dead time 1.0uS dead time 1.5uS dead time

External 12MHz crystal oscillator

PWM carrier frequency 23.4KHz

Voltage, current, real-time temperature feedback

Overvoltage, undervoltage, overcurrent and overtemperature protection

Soft-start mode pin setting response time is 1S

Serial port communication to set output voltage, frequency and other parameters

External serial port LCD module 1602 display inverter




Voltage, frequency, temperature and current information




application:
Single Phase Pure Sine Wave Inverter
Photovoltaic inverter
wind power inverter
Uninterruptible Power Supply UPS System
digital generator system
IF power supply
Single-phase motor speed controller
single phase inverter
Sine wave dimmer
Sine wave regulator
sine wave generator



Package Included:

1 x DC-AC Pure Sine Wave Inverter Driver Board EGS002 EG8010 + IR2113 Driver Module
