Goodprice EAST TESTER ET431 Series Handheld LCR Bridge Tester Capacitance Inductance Resistance Appliance Repair Multimeter

Supplier: Dongmi Electric (xiamen) Co., Ltd.
Region: Fujian, China
Price: $96.83 / 5 - 999 pieces
$86.91 / 1000 - 4999 pieces
$77.26 / >=5000 pieces
Min. Order: 5 pieces

Click here to contact

Product details

payment terms:	wire transfer	brand:	Oriental Tester
Warranty:	other	type:	Handheld
model:	ET431	Display digits:	Primary parameter: 5 digits Secondary parameter: 5 digits
Model:	ET430	Basic precision:	0.3%
Test level:	0.3%	level of accuracy:	0.3%
Display:	display screen	Origin:	China
Test frequency:	100Hz, 120Hz, 1KHz, 10KHz, 40kHz, 100KHz

brand

Specification

Model	ET430	ET431	ET432	ET433
test frequency	100 Hz, 120 Hz, 1KHz, 10KHz, 40kHz, 100kHz	100Hz, 120Hz, 1KHz, 10KHz	100Hz, 120Hz, 1KHz, 10KHz, 40kHz, 100KHz	100Hz-100KHz Continuously adjustable, 1 Hz as step size
basic accuracy	0.3%	0.2%	0.2%	0.2%
display screen	2.8 inch TFT LCD screen
display digits	Main parameters: 5 digits Secondary parameter: 5 digits
Measurement parameters:	Main parameters: L/C/R/Z Secondary parameters: X/D/Q/θ/ESR
Electrolytic capacitor method	√	√	√	√
DCR mode	x	√	√	√
Measuring range	L: 0.000μH～2000H, C: 0.000pF ~ 20.000mF, On-resistance: 0.0001Ω～20.000MΩ
Measure display speed	1 time/second (slow), 2 times/second (medium), 4 times/second (fast)
internal deviation	x	0-500mV adjustable, step 1mV.
test level	300mVrms, 600mVrms	100mVrms, 300mVrms, 600mVrms, 1Vrms			10mV-1100mV adjustable
Calibration function	Open calibration, short calibration
filter function	The filter limit range can be set from 1% to 50%, and the fixed points are 1%, 5%, 10%, 20%.
Deviation measurement	Used to compare and display the percentage deviation of components from the set nominal value
others	Backlight brightness adjustment, Chinese and English optional, USB device and automatic shutdown time
Accessories
Standard configuration	1. Mini USB cable; 2. Power adapter; 3. Shorting bar; 4. Red and black rubber plug; 5. High-capacity lithium battery
Standard configuration		/	Kelvin clip
Optional	Kelvin clip SMD clip	SMD clip
