Electronic Test and Measurement Instrument,3 phases power analyzer, FU2200 power Meter

Supplier: Beijing GFUVE Electronics Co., Ltd.
Region: Beijing, China
Contact: Mr Andy Huang
Price: $265.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

FU2200:	power analyzer meter;	Mounting Panel:	120 X 120mm;
RTC:	Year;	Thickness:	21mm;
Month:	Second;	Dimensions:	120 X 120mm;
Payment Terms:	T/T,Western Union,paypal;	Brand Name:	GFUVE;
Baud:	1200~19200;	Supply Ability:	10000 Piece/Pieces per Month;
Accuracy Class:	0.5%,1%;	Measuring Voltage Range:	30~600V;
Operating Temperature:	-25 ~ 55 °C;	Port:	Beijing/Shanghai/Shenzhen;
Transformation Ratio:	PT, CT.;	Measuring System:	3P4W/3P3W etc;
Parity Bit:	N/E/O;	Measuring Current Range:	0~6A;
Model Number:	FU2000;	Packaging Detail:	standard export carton;
Place of Origin:	Beijing China;	Address:	1~247;

Introduction

FU2200 is a multifunction power analyzer, It can measure all the electric parameters in the circuit, and it has RTC, calendar and one pulse output.

FEATURES

Can measure all the electrical parameters
Four modules can choose
Can measure the harmonics
High accuracy 0.5s
PT,CT transformation ratio is settable

PARAMETERS

Electrical parameters
Power supply (AC/DC)	AC85-265V / DC85-330V, DC18-90V (optional) Power consumption: <4VA
Measurement parameters	Voltage (Ph-N); Voltage (Ph-Ph); Current; Frequency; PF; Active Power(W); Reactive Power(Q) ; Apparent Power(S), 3^rd-19^th harmonics
Harmonics	Total harmonics ratio of phase-voltage Total harmonics ratio of current 3^rd-19^th harmonics ratio of Phase-voltage (RS485 output) 3^rd-19^th harmonics ration of current (RS485 output)
Maximum value	Max. value for voltage/current Max. value for active power Max. value for reactive power Max. value for apparent power
Computation	Forward active power energy Reverse active power energy Forward active power energy Reverse reactive power energy
Measuring range	30-600V, 0-6A, 45-65Hz, -1 ~ 0 ~ 1
Measuring accuracy	Frequency: 0.1% Electric energy: 0.5%, 1.0% Voltage : 0.2%±0.1V Current : 0.2%±0.001A Power : 0.5% ±0.4W Power factor : 0.5% ±0.001
Display	Wide screen angle; Light blue back-lit LCD display; 5 display figures; 6 operation keys.
Communication	RS-485 interface port support, 32 (128) Networking, ModBus-RTU communication protocol
Programmable	Measuring system: 3P4W/3P3W etc. Transformation ratio : PT,CT. Communication: Address: 1-247; Baud: 1200-19200; Parity bit: N/E/O Energy: reset
Energy pulse (expansion)	FM-E2 provides active & reactive energy pulse output. 6 pulse parameters can be choose. Range: 0.1-10000kWh/kvarh; Dry contact output (1AX100V).
Data collection (expansion)	Each FM-K2 module can collect 2-ways dry contact counting
Control (expansion module)	Each FM-K2 provides 2 relay contact outputs, which can be controlled by communication or the measured parameters.
Analog output (expansion module)	Each FM-A20 module provides 2 ways of DC 4-20mA outputs, the function-relations can be set according to the measured parameters.
Connection mode	3P4W, 3P4W BAL, 3P3W, 3P3W BAL, 1P2W, 1P3W
Mechanical parameters
Dimensions (mm)	Mounting panel: 96x96 Thickness: 20 Depth: 60 (without expansion module) 80 (without expansion module)
Mounting	Panel mounting Trepanning: 92x92mm
Environmental conditions
Temperature	-25 to +50°C
Humidity	20%-95%RH, Without condensation
