Single gross weight: | 4.0 KG; | CPU: | Celeron 2980U; |
Dimensions (W x D x H): | 440*250*44.5 mm; | LAN: | 6*82583V Lan; |
Memory: | 1G DDR3 RAM; | Storage: | 16G MSATA SSD; |
Operating System: | Pfsense/openwrt; | Single package size: | 50X35X10 cm; |
Selling Units: | Single item; | Model Number: | 2980U-6LAN-1G-16G; |
Specification | ||
Model | 2980U-6LAN | |
Case Color | Black(color can be customized) | |
Material | High-quality pure aluminum | |
CPU | Intel® Celeron® Processor 2000 Series
| |
Mainboard | 170*170mm mini ITX mainboard | |
RAM | 1*SO-DIMM DDR3L, support max 8G | |
Storage | 1*MSATA, 1*2.5''/3.5'' HDD, | |
Audio | N/A | |
Display Interface | 1*VGA | |
Display | Integrated Intel HD Graphic card, support 1*VGA | |
I/O | 2*USB3.0 |
|
| 1*VGA |
|
| 1*HDD LED |
|
| 6*Intel Lan |
|
| 1*Power LED |
|
| 1*Power Switch |
|
| 1*AC 220V |
|
Network Card | 6*Intel 82583V 1000M lan, support wake on lan | |
Expansion | 1*mini-PCIE(support MSATA) | |
Watch Dog Timer | Support | |
Power Supply | AC 110V~240V power supply | |
Operating System | Windows 7/8/10, Linux, Pfsense | |
BIOS | AMI 64M DPI Flash ROM | |
Working Temperature | -10°C - 60°C | |
Working Humidity | 0% - 95% relative humidity, Non-condensing | |
Size | 440*250*44.5 mm (L*W*H); | |
Net Weight | 5kg; |
