Rotary vacuum disc filter for mining solid-liquid filtration
-
Supplier: Lianyungang Boyun Machinery Co., Ltd. -
Region: Jiangsu, China -
Contact: Ms Kristen Zhou -
Price: $5000.00 /piece -
Min. Order: 1 piece
| Condition: | New; | Port: | Shanghai, Qingdao, Lianyungang; |
| Filter Media: | Filter cloth; | Number of Filter Disks: | 4; |
| Brand Name: | boyun; | Product name: | disc filter; |
| Filter Disc Diameter: | 210CM; | Outline Dimension: | 449*248*269cm; |
| Place of Origin: | Jiangsu China (Mainland); | Packaging Detail: | Nude package combined with standard export wooden case package or as customer's requirements.; |
| After-sales Service Provided: | Engineers available to service machinery overseas; | Supply Ability: | 1000 Piece/Pieces per Month disc filter; |
| Payment Terms: | T/T,Western Union; | OEM: | yes; |
| Discharge Method: | reverse wind; | Main Motor Power: | 5.5kw; |
| Filter Area: | 20㎡; | Number of Filter Fans: | 80; |
Filter diameter(mm) | 2100 | 3100 | |||||||||||
Filtration area (m2) | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 48 | 60 | 72 | 84 | 96 | |
Filter disc quantity | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 4 | 5 | 6 | 7 | 8 | |
Quantity of each filtration disc | 20 | 20 | |||||||||||
Principal shaft power (KW) | 4 | 5.5 | 7.5 | ||||||||||
Mixer shaft power (KW) | 35.5 | 7.5 | 11 |
| |||||||||
Cake discharged way | reverse blow |
| |||||||||||
Weight of machine(t) | 10.4 | 11.0 | 11.6 | 12.2 | 12.8 | 13.4 | 14.0 | 18 | 21 | 24 | 27 | 30 | |
Size | L(mm) | 2535 | 2920 | 3315 | 3705 | 4095 | 4485 | 4875 | 4175 | 4675 | 5175 | 5675 | 6175 |
W(mm) | 2480 | 4280 | |||||||||||
H(mm) | 2690 | 3740 | |||||||||||
Capacity (t/h) | 0.6-0.85 | 0.6-0.85 | |||||||||||
Q1:Could you provide OEM service?
Yes, we have strong R&D capacity and technical support to customize the products according to customer’s requirements.
Q2:What about the payment term?
We can accept T/T, Western Union, Paypal.
Q3:Could you provide samples?
Yes.
Q4:Do you provide the technical support?
Yes, we have a experienced technical team to provide the pre-sales and after-sales supporting.
Q5:How does your factory do regarding quality control?
We have professional QC team and test equipments to ensure the quality.
-
