Packaging Details: | Everyone has a bubble bag. The outer packaging is a wooden box. or according to customer requirements | place of origin; place of origin: | Jiangsu, China |
weight: | Specification | brand: | New Jersey JR |
Main selling point: | easy to operate | standard: | 3A, SMS, DIN, BPE |
Showroom location: | not any | payment terms: | L/C,D/P,D/A,T/T |
port: | Shanghai/Tianjin | Weight (kg): | 400 |
Video external inspection: | if | Dimensions (L*W*H): | customized |
Mechanical test report: | if | Marketing Type: | normal product |
Material: | SS304, SS316 | Core Components Warranty: | 1 year |
Packaging Preview: | Applicable industries: | pharmacy | |
Health status: | new | Warranty: | 1 year |
Core components: | PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump | capacity: | 100-20000L |
After-sales service provided: | Online support |
Specification | Inner tank diameter (Фmm) | Jacket diameter (mm) | Insulation layer (Фmm) | Motor power (kw) | mixed spin speed |
30 | 300 | 350 | 450 | 0.6-1.1 | 60-120 |
50 | 400 | 450 | 550 | 0.6-1.1 | 60-120 |
100 | 500 | 550 | 650 | 1.1-1.5 | 60-120 |
150 | 550 | 600 | 700 | 2.2 | 60-120 |
200 | 600 | 650 | 750 | 2.2 | 60-120 |
300 | 700 | 750 | 850 | 2.2 | 60-120 |
500 | 800 | 900 | 1000 | 2.2 | 60-120 |
800 | 1000 | 1100 | 1200 | 4 | 60-120 |
1000 | 1000 | 1100 | 1200 | 4 | 60-120 |
1500 | 1100 | 1200 | 1300 | 4 | 60-120 |
2000 | 1250 | 1350 | 1450 | 4 | 60-120 |
2500 | 1400 | 1500 | 1600 | 7.5 | 90-120 |
3000 | 1500 | 1600 | 1700 | 7.5 | 90-120 |
3500 | 1400 | 1500 | 1600 | 7.5 | 90-120 |
4000 | 1600 | 1700 | 1800 | 7.5 | 60-120 |
5000 | 1900 | 2000 | 2100 | 7.5 | 60-120 |
6000 | 1900 | 2000 | 2100 | 15 | 100-120 |
8000 | 2000 | 2100 | 2200 | 15 | 100-120 |
