industrial crystallization equipment PET PLA flake Crystallization Vacuum evaporative crystallization equipment

Product details
Main selling points:easy to operatePackaging Details:Film cover or plywood box
Material:stainless steel SS304Core component warranty:1 year
strength:7.5KWWarranty:1 year
Core components:PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pumpMarketing Type:normal product
port:Shanghaiplace of origin; place of origin:Jiangsu, China
payment terms:L/C, Western Union, T/T, MoneyGramDimensions (L*W*H):940*1200*2390
Voltage:380Vvolume:300-5000L
Health status:newVideo shipment inspection:if
Weight (kg):350Mechanical test report:Not available
Supply capacity:100 sets per monthAfter warranty service:1 year
Showroom location:not anybrand:Turi
Applicable industries:manufacturing plantproduct name:Industrial crystallization equipment
Product Description
Specification
thing
value
place of origin; place of origin
China
Jiangsu
brand
Turi
Health status
new
Video shipment inspection
if
Mechanical inspection report
Not available
marketing type
normal product
Core component warranty
1 year
core components
PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump
Voltage
380V
strength
7.5KW
Dimensions (L*W*H)
940*1200*2390
Warranty
1 year
main selling point
easy to operate
Applicable industry
manufacturing plant
Showroom location
not any
Weight (kg)
350
product name
Industrial crystallization equipment
Material
stainless steel SS304
volume
300-5000L
After Warranty Service
1 year
Features: 1. Wall-mounted vortex air inlet, the whole crystallization process takes 1 hour to 2 hours, high efficiency and energy saving, uniform 2. The structure conforms to the principle of fluid mechanics, avoiding insufficient crystallization caused by uneven airflow 3. The barrel structure conforms to the mechanical principle, Avoid unilateral cutting and ensure drying time 4. Uniquely designed mixing blades and positioning rods can effectively prevent material agglomeration 5. When equipped with a dehumidifier, the conveying pipeline uses dehumidifying wind to replenish air to prevent humid air from entering the barrel. 6. Double-layer insulation design, the inner layer is stainless steel, the middle layer is insulation cotton, and the outer layer is embossed aluminum plate
Model
300U
600U
1000U
1600U
2500U
3500U
5000U
Volume (L)
300L
600L
1000L
1600L
2500 liters
3500 liters
5000L
Loading capacity (kg)
Bulk density p=0.5~0.85kg/L
180
360
600
960
1500
2100
3000
Loading capacity (kg)
Bulk density
p=0.3~0.5kg/L
100
210
350
560
870
1200
1700
Length (mm)
940
1165
1310
1760
1790
2130
2172
Width (mm)
1200
1300
1580
3608
3725
3836
4126
height (mm)
2390
2900
3746
4383
4763
5015
5566
Weight (kg)
350
450
960
1735
1950
2110
3200
