HOT SALE! NEW SIGLENT Arbitrary Function Signal Generator SDG1050 50MHz 125MSa/s 16Kpts 48

Product details
Place of Origin:Guangdong China;Model Number:SDG1050;
Payment Terms:L/C,T/T,Western Union,MoneyGram,paypal;Brand Name:graigar;
Packaging Detail:standard export carton;Supply Ability:500 Piece/Pieces per Week;
Port:shenzhen;Delivery Detail:7 days;

HOT SALE! NEW SIGLENT Arbitrary Function Signal Generator SDG1050 50MHz 125MSa/s 16Kpts 48



PRODUCT DESCRIPTION



  • Main Features:

    • Apply DDS technology, double output, adjustable phase, the highest output frequency is 50MHz.
    • 125MSa/s sample rate, 14bit vertical resolution, 16Kpts wave length.
    • Output 5 types of standard waveform, internally installed 48 types of waveform;
    • Internally installed high precision, wide frequency counter, frequency is up to 200MHz.
    • Abundant modulation function, sweep-frequency output, pulse train output.
    • Standard collocation connection: USB Device, USB Host, support U Disk storage and software upgrading;
    • GPIB and LAN port are optional.
    • Can connect to SDS1000 series digital oscilloscope perfectly, and support remote command control.

    Specification:

    Model

    SDG1005

    SDG1010

    SDG1020

    SDG1025

    SDG1050

    highest frequency output

    5MHz

    10MHz

    20MHz

    25MHz

    50MHz

    output channels

    2

    sample rate

    125 MSa/s

    wave length

    16 Kpts (channel one can choose 512Kpts)

    frequency resolution

    1μHz

    vertical resolution

    14 Bit

    waveform

    Sine wave, square wave , triangular wave , pulse wave ,white noise,48 types of function waveform

    Sine wave

    1μHz ~ 5MHz

    1μHz ~ 10MHz

    1μHz ~ 20MHz

    1μHz ~ 25MHz

    1μHz ~ 50MHz



    square wave

    1μHz ~ 5MHz

    1μHz ~ 10MHz

    1μHz ~ 20MHz

    1μHz ~ 25MHz

    1μHz ~ 25MHz



    pulse

    1μHz ~ 5MHz

    1μHz ~ 10MHz

    1μHz ~ 10MHz

    1μHz ~ 10MHz

    1μHz ~ 10MHz



    Ramp

    1μHz ~ 300KHz

    1μHz ~ 300KHz

    1μHz ~ 300KHz

    1μHz ~ 300KHz

    1μHz ~ 300KHz



    Gaussian white noise

    5MHz bandwidth(-3dB)

    10MHz bandwidth(-3dB)

    20MHz bandwidth(-3dB)

    25MHz bandwidth(-3dB)

    50MHz bandwidth(-3dB)



    wave

    1μHz ~ 5MHz

    1μHz ~ 10MHz

    1μHz ~ 10MHz

    1μHz ~ 10MHz

    1μHz ~ 10MHz



    modulation function

    AM,FM,PM,ASK,FSK,PWM etc.

    other functions

    Frequency counter:frequency is up to200MHz

    Standard configuration

    USB Host & Device

    Optional port

    GPIB(IEEE-488),LAN

    product classify

    function/waveform generator

    size

    widthheightdepth=229mm105mm281mm

    Standard Accessories

    • One Power Cord that fits the standard of destination county
    • One USB Cable
    • One User Manual
    • One Set Of UltraWave for WIN98/2000/XP arbitrary Waveform Drawing software

    Optional Accessories

    • BNC Coaxial cable
    • GPIB/LAN Interface
