High Stability ZTB 2 Pin 455KHz Ceramic Resonator 455E

Supplier: WTL International Limited
Region: Guangdong, China
Price: $0.025 / >=10 pieces
Min. Order: 10 pieces

Click here to contact

Product details

Supply Ability:	1000000 Piece/Pieces per Month Ceramic Resonator 455E;	Operating Temperature Range:	-20 ~ +80'C;
Model Number:	WTL2.00645ZX;	Brand Name:	WTL;
Storage Temperature Range:	-30 ~ +85'C;	Warranty:	Global 180 Days Return;
Package:	OPP Bag + Carton;	Frequency Stability:	±0.3%;
Frequency Accuracy:	±2KHz;	Payment Terms:	L/C,T/T,Western Union,Paypal;
Shipment:	DHL, UPS, TNT,Fedex, EMS,China Post;	Cetificate:	ISO9001, ISO14001, SGS, RoHS;
OEM/ODM:	Welcome;	Port:	Shenzhen;
Place of Origin:	Guangdong China (Mainland);	Packaging Detail:	Opp Bag+Carton, 500pcs/Bag(High Stability ZTB 2 Pin 455KHz Ceramic Resonator 455E);
Center Frequency:	455.000KHz;

High Stability ZTB 2 Pin 455KHz Ceramic Resonator 455E

WTL----Win-win To Long

WTL is a professional manufacturer of Quartz Crystal Electronic Components in China, Established in 2001, Which Specializes in researching & developing, producing and marketing, WTL offers kinds of crystals in order to pace with wide applications.whatever you do need ,standard or high-class requirement on special fields, we will support you right quartz crystal resonator and oscillator with 100% repliability insurance.

Website: www.wtlcrystals.com

SCOPE

This specification relates to piezoelectric ceramic resonator to be used in a clock generating circuit

for microprocessors.

ELECTRICAL CHARACTERISTICS

ZTB Ceramic Resonator DIP Type
Item	Specifications
P/N	WTL2.00645ZX
Center Frequency	455.000KHz
Frequency Accuracy(25°C)	±2KHz
Frequency Stability	+/-0.3% Max
Operating Temperature Range	-20°C to +80°C
Storage Temperature Range	-30°C to +85 °C
Withstanding Voltage	DC 100V
Resonator Impedance	20Ω Max
Aging for ten years	+/-0.3% Max

High Stability ZTB 2 Pin 455KHz Ceramic Resonator 455E

Packaging & Shipping

Our Services

1.19 Years Experience

2.PCB VS Crystal Matching Test for Free

3.FAE Support

4.Certification: ISO9001, ISO14001, SGS, RoHS

5.Provide A Full Set of Reliability Lab

6.Door to Door Service

7.Global 180 Days Return

8.Over 72 Countries and Regions, 27 Distributors

9.Custom-made Frequencies Due to we have our own Wafer Production Line

Our factory has a history of 19 years and it is located on Tongling City, Anhui Province, China. It covers an area of 6000 square meters. It has over 200 workers, Include Production, QA, QC, Warehouse, R&D, Technical, IQC. Welcome to Our Factory!

FAQ

1.What is the general lead-time of the products?

Product	Lead Time
HC49 Series	1-2 weeks
SMD Crystal	1-4 weeks
DIP Oscillator	1-2 weeks
SMD Oscillator	1-3 weeks
TCXO	2-8 weeks
Watch Crystal	1-2 weeks

2.Since the lead-time is set, what about samples?

Usually the samples are needed the same lead time. By the way, we can offer each customer 10-20PCS samples free of charge.

3.What basic information to provide when ordering a crystal?

Generally we request the customer to provide the center frequency, type of cutting angle(AT/BT), holder or package type, resistance(ESR), frequency tolerance, frequency stability, load capacitance, operating temperature, drive power, aging, etc, Customer can also specify other specific spec or requirement, if any, when placing orders.

4.What is the WTL main material?

Type	Vendor
Crystal Bar	South Urals,Russia- Crystal Factory, TF
Base	SMI/NTK/KYOCERA(JP)
IC	NPC- Japan
Top Cover	Hua Nu Dike/Yoshikawa Corporation (JP)
Conductive Glue	Three Bond – (JP)
