Wavelength Range: | 200nm~900nm for Emission; | Payment Terms: | L/C,T/T,Western Union; |
Model Number: | SP-F98; | Packaging Detail: | package suitable for export; |
Supply Ability: | 100 Set/Sets per Month; | Port: | any port in China; |
Weight: | GW 25kg, NW 21kg; | Size: | 610mm*460mm*365mm; |
Place of Origin: | Guangdong China; | Brand Name: | Labgeni; |
warranty: | 1 year; |
Specifications:
Model |
SP-F98 |
Detection sensitivity (water Raman peak signal noise ratio) |
S/N ≥250 (P-P) or 800(RMS) |
Excitation wavelength Bandwidth |
1nm/2nm/5nm/10nm/20nm |
Emission wavelength Bandwidth |
1nm/2nm/5nm/10nm/20nm |
Minimum sample volume |
0.5ml(using 10mm sample pool) |
Wavelength accuracy |
±0.4nm |
Wavelength repeatability |
≤0.2nm |
Light source |
150W automatic deodorizing xenon lamp (Hamamatsu, Japan) |
Optical system |
Double-grating monochromator automatic wavelength scanning with optical excitation double beam ratio monitoring |
Fluorescence Receiver |
Original photomultiplier (Hamamatsu, Japan) |
Excitation wavelength range |
200nm~900nm |
Emission wavelength range |
200nm~900nm |
Wavelength scanning speed |
10 positions, fastest 60000nm/min |
Measurement line |
≥0.995 |
Gain adjustment range |
1~17 position optional |
Integral Response time |
7 position options: 8s ~ 20ms |
Data output |
Microsoft (R) Excel format, bmp image format |
Data transmission |
USB2.0 Interface |
Light value range |
-9999~9999 |
Peak intensity Repeatability |
≤1.5% |
Power source |
220V / 50Hz, 110V / 60Hz |
Standard energy consumption |
200W |
Dimensions (mm) |
610mm×460mm×365mm |
Weight |
21kg |
